Page 480 - 2017 Racecar Engineering Circle Track Parts and Accessories Catalog

POWER CHARGER THRU PANEL BATTERY CON NEC TOR
MOR74016 MOR74145
The versatile Power Charger can be Used wher ev er a bat tery cable, or oth er large di am e ter,
used to charge a wide variety of 12- or high am per age ca ble, passes through a firewall or sim i lar
16-volt battery types including pan el. Fits through 1-1/4" hole and is held sol id ly by
gel cell, sealed, lead acid, wet/ in clud ed span ner kit. Use MOR74170 Bat tery Cable Re mote
deep cycle, “Reactor” and Fit ting End Kit to complete in stal la tion.
AGM. Charger includes 30 amp
rating for quickest recharge and low start BATTERY QUICK-CONNECT PLUGS
voltage for batteries that are discharged
Useful for race cars, tow vehicles, winches, etc., the kit includes male and
to as little as .02 volts. Short and reverse polarity female plugs, and terminals to connect the vehicle to a battery charger. Avail-
protection adds safety. Large handle eases carrying.
able in large or mini- size.
BATTERY DIS CON NECT SWITCHES
A Battery Disconnect Switch is one of the
most critical safety devices in a race car. MOR74200
Turning the non-slip handle cuts power to all MOR74201
electrical devices including ig ni tion.
Part No. Description
Part No. Description
MOR74100 For Cars Without Alternator, 125 Amps MOR74200 Large Battery Quick Disconnect Plug
MOR74101 For Cars With Alternator, 175 Amps MOR74201 Mini-Battery Quick Disconnect Plug,
Up To 50 Amps Using #6 Wire
SUPER-DUTY BATTERY
DISCONNECT SWITCH STARTER HEAT SHIELDS
MOR74102 Excessive heat not only cuts short
Super-Duty switch includes two pairs of the life of a start er, but also reduces
copper studs for shutting down the entire the start er’s crank ing power. Start er
electrical system, useful when race car is fitted Heat Shield provides pro tec tion from
heat on race cars and tow ve hi cles.
with an alternator. Rated at 2,000 amps intermittent and
300 amps continuous. Includes face plate and on/off decal. Consists of high tem per a ture in su lat-
ing ma te ri al sand wiched be tween two
sheets of aluminum.
BATTERY CABLE KIT Part No. Description
MOR74005 Fits SBC/BBC MOR74299 MOR74300
Rugged 2 gauge copper battery cable kit MOR74299 With Tilton Starter
will with stand the high am per age load ing MOR74300 Fits SBC/BBC
nec es sary to start high per for mance racing With Delco Starter
en gines, es pe cial ly if the bat tery is re lo cat ed
to the rear. 20' coil with four ter mi nal ends. PUSH BUTTON STARTER SWITCH
MOR74120
BATTERY CABLE REMOTE Waterproof and dust proof push button start er
FITTING END KIT MOR74170 switch has neo prene cap for in-car or underhood
Quality, screw-together bat tery cable ends for mounting. 35 amp rated at 12 Volts.
side post batteries are ideal for splicing in battery
dis con nects, remote jumper terminals or junction
blocks. Two per package.
TOGGLE SWITCHES
BATTERY POST High quality toggle switches, in traditional on/off, single
TERMINAL END KIT throw or momentary designs, include on/off faceplates and
are rated at 20 amps lamp load and 35 amps inductive load.
MOR74175 Momentary switch is ideal for use as a starter switch.
Same as MOR74170 ex cept for top post Part No. Description
batteries. Two per package. Momentary Toggle Switch,
MOR74124
Long 1-1/2" Handle
REMOTE BAT TERY MOR74125 On/Off Toggle Switch, Long 1-1/2" Handle
JUMPER TER MI NALS MOR74126 On/Off Toggle Switch, Short 11/16" Handle MOR74126
MOR74140
Place the battery anywhere
in the car and it will still be
ac ces si ble between races for charg ing
with remote jumper terminals. Terminals
can be po si tioned in the most con ve nient spot, inside or
out side of the car, and connected to the battery with a high
amperage cable such as the Moroso MOR74005. Universal for
6-36 Volt systems. Two per pack age.
MATT BEX MARK SCHAEFER
479
