ELECTRICAL, GAUGES & IGNITION

Primary Wire Heat Shrink Tubing ALL76160
Single conductor stranded copper wire Place tubing over wiring
with polyvinyl insulation which remains before attaching terminal
flexible and is abrasion resistant. Stranded end then slide over crimped
copper is the wire of choice for many terminal end, heat to seal
projects when building custom wire har- and strengthen connection.
nesses or adding accessories. 30-piece kit includes a variety
of sizes including 1/16", 1/8", 3/16", 1/4", 3/8" and 1/2".
20AWG
Used for low voltage sensors, indicator
lights, instrument panel or dash lighting. Grommet Set ALL18360
Grommets are perfect for protecting
Color 50' Coil 100' Spool
Red ALL76500 ALL76510 wiring and hoses that pass through
Black ALL76501 ALL76511 panels up to 1/16" (.062") thick. Kit
White ALL76502 ALL76512 includes 36 grommets (6 of each size: 1/4",
Green ALL76503 ALL76513 5/16", 3/8", 1/2", 5/8" and 11/16"). Grommets
Yellow ALL76504 ALL76514 are also available in size specific 10-packs.
Brown ALL76505 ALL76515
Blue ALL76506 ALL76516 Part No. Grommet Hole I.D. Panel Hole I.D.
ALL18362 3/16" 5/16"
14AWG ALL18363 1/4" 3/8"
Most popular when fabricating harnesses for general use ALL18364 5/16" 7/16"
including lighting of headlights, taillights and brake lights, ALL18365 3/8" 1/2"
ALL18366
1/2"
5/8"
ignition systems and interior accessories such as radios, ALL18367 5/8" 7/8"
interior fans and gauge panels. ALL18368 11/16" 1"
Color 20' Coil 100' Spool
Red ALL76540 ALL76550 Braided Wire Wrap
Black ALL76541 ALL76551 Split loom braided
White ALL76542 ALL76552 wrap is easily NEW!
Green ALL76543 ALL76553 applied over existing hoses or wiring to conceal and
Yellow ALL76544 ALL76554 protect against wear or abrasion. Wrap features a 25
Brown ALL76545 ALL76555
Blue ALL76546 ALL76556 percent overlap based on the nominal size listed, allowing
the wrap to bend and flex without opening. Wrap is
12AWG constructed of polyethylene material, heat resistant up to
Wire can be used to supply power to ignition boxes, 250°F and easily cuts with a hot knife or a soldering iron
cooling fans, fuel pumps and other higher amperage with knife attachment.
accessories including power to electric trailer brakes. ALL76610 ..... 1/8" x 20' ALL76616 ...... 3/4" x 5'
Color 12' Coil 100' Spool ALL76612 ..... 1/4" x 15' ALL76618 ...... 1" x 10'
Red ALL76560 ALL76565 ALL76614 ..... 1/2" x 10'
Black ALL76561 ALL76566
White ALL76562 ALL76567 Spiral Wire Loom
Blue ALL76563 ALL76568
Loom keeps wiring bundled
10AWG together for a neat appearance
Commonly used for higher amperage applications and can be easily removed when adding or removing wires
including alternator charging wire and supplying power during wiring harness changes. Open design makes identifying
to trailer for interior lighting or charging trailer batteries or locating a wire simple and will not hold dirt and moisture like
when utilizing tow vehicle charging system. solid looms. Loom also provides provide abrasion resistance to
protect wiring or hoses. High density polyethylene material is
Color 10' Coil 75' Spool rated from -30°F to 165°F and sold in 10 ft. lengths.
Red ALL76570 ALL76575
Black ALL76571 ALL76576 ALL76600 ..... 1/4" ALL76604 ..... 3/4"
White ALL76572 ALL76577 ALL76602 ..... 1/2"
Wire And Cable Cutters
ALL11003
Capable of cutting copper stranded wire from
20 gauge primary wire to 1/0 gauge battery
cable. These specially designed cutters will not
flatten wire during cutting which is helpful when
installing connectors and building battery cables.
Cutters are not designed to cut steel wire.
Photo: John Berglund
