Drum HanDling
DRUM StORaGe
Storage and handling solutions

DRUM StORaGe PaLLet SySteMS
• comply to control of Pollution (Oil Storage)
(england) Regulations 2001
A safe and secure system for storage and transportation of liquids.
Designed to hold the contents of drum spillage.
A wide range of drum storage options for storing either 2 or 4 drums.
Fork guides combine to give a safe and secure lift when stacking.
The two sump trolleys are mobile on 125 mm rubber castors, 2
fixed, 2 swivel braked. Model DH951S holds one drum horizontally.
The drum cradle is fitted with four rollers which enables the drum to
rotate. Model DH952S holds two drums vertically.
DH904Z
• fork centres 550 mm • all swivel castors

DH904S DH914S DH914Z

DH952S DH951S
Static Model Mobile Model
Overall Overall Sump
Description Width Length Capacity Overall Ground Weight Overall Ground Weight
Height Clearance Model Price Height Clearance Model Price
mm mm Litres Kg Kg
mm mm mm mm
DRUM STORAGE PALLETS - STORED VERTICALLY - NON STACKABLE WHEN LOADED
2 Drum 850 1360 247 540 150 66 DH902Z POA 580 190 81 DH902S POA
4 Drum 1480 1360 432 540 150 110 DH904Z POA 580 190 125 DH904S POA
DRUM STORAGE PALLETS - STORED VERTICALLY - STACKABLE 3 HIGH - 3 REMOVABLE SIDES
2 Drum 850 1360 247 1470 150 90 DH912Z POA 1510 190 105 DH912S POA
4 Drum 1480 1360 432 1470 150 150 DH914Z POA 1510 190 165 DH914S POA
DRUM STORAGE PALLETS - STORED HORIZONTAL - 2 FIXED SIDES - REAR OPENING DOOR
2 Drum 1360 1500 432 1300 150 245 DH922Z POA 1340 190 260 DH922S POA
4 Drum 1360 1500 432 1960 150 290 DH924Z POA 2000 190 305 DH924S POA
SUMP TROLLEYS
1 Drum 700 1500 247 1000 200 80 DH951S POA
2 Drum 700 1500 247 1000 200 70 DH952S POA

127
