Page 258 - 2022-23 Auto Performance Open Wheel Catalog

VB Series 2-1/2" I.D. Coil-Over Springs
VB Series 2-1/2" I.D. coil-over springs are manufactured from premium chrome silicon wire and are engineered to offer an accurate spring rate and long service life. Each spring is preset to solid height during the manufacturing process and is sold complete with a dyno sheet to ensure superior accuracy and quality control.
Rate 4" Tall
10" Tall
12" Tall
2-1/4" I.D. Coil-Over Springs
Part No.
Description
LANY7-400
7" Tall, 400 lb. Rate
LANY7-475
7" Tall, 475 lb. Rate
LANY7-500
7" Tall, 500 lb. Rate
LANY7-525
7" Tall, 525 lb. Rate
LANY8-150
8" Tall, 150 lb. Rate
LANY8-175
8" Tall, 175 lb. Rate
LANY8-200
8" Tall, 200 lb. Rate
LANY8-225
8" Tall, 225 lb. Rate
LANY8-250
8" Tall, 250 lb. Rate
LANY8-275
8" Tall, 275 lb. Rate
LANY8-300
8" Tall, 300 lb. Rate
LANY8-325
8" Tall, 325 lb. Rate
LANY8-350
8" Tall, 350 lb. Rate
LANY8-375
8" Tall, 375 lb. Rate
LANY8-400
8" Tall, 400 lb. Rate
125
—
—
LAN12VB125
150
—
—
LAN12VB150
200
—
—
LAN12VB200
225
—
LAN10VB225
LAN12VB225
250
—
LAN10VB250
LAN12VB250
275
—
—
LAN12VB275
300
—
LAN10VB300
LAN12VB300
400
LAN4VB400
LAN10VB400
LAN12VB400
475
—
LAN10VB475
—
500
—
LAN10VB500
—
550
—
LAN10VB550
—
600
—
LAN10VB600
—
650
—
LAN10VB650
—
1.9" I.D. Variable Body Coil Springs
Springs provide a high rate of travel and are lighter in weight, resulting in increased linear spring rate.
Part No.
Description
LANX6-200 6" Tall, 200 lb. Rate
LANX6-220 6" Tall, 220 lb. Rate
LANX6-240 6" Tall, 240 lb. Rate
LANX6-260 6" Tall, 260 lb. Rate
LANXVB060 8" Tall, 60 lb. Rate
LANXVB075 8" Tall, 75 lb. Rate
LANXVB110 8" Tall, 110 lb. Rate
LANXVB160 8" Tall, 160 lb. Rate
LANXVB170 8" Tall, 170 lb. Rate
LANXVB180 8" Tall, 180 lb. Rate
LANXVB190 8" Tall, 190 lb. Rate
LANXVB200 8" Tall, 200 lb. Rate
LANXVB220 8" Tall, 220 lb. Rate
LANXVB260 8" Tall, 260 lb. Rate
LANXVB280 8" Tall, 280 lb. Rate
LANXVB300 8" Tall, 300 lb. Rate
LANXVB320 8" Tall, 320 lb. Rate
LANXVB350 8" Tall, 350 lb. Rate
LANTVB110 10" Tall, 110 lb. Rate
LANTVB120 10" Tall, 120 lb. Rate
LANTVB130 10" Tall, 130 lb. Rate
LANTVB140 10" Tall, 140 lb. Rate
LANTVB150 10" Tall, 150 lb. Rate
LANTVB160 10" Tall, 160 lb. Rate
LANTVB170 10" Tall, 170 lb. Rate
LANTVB180 10" Tall, 180 lb. Rate
LANTVB190 10" Tall, 190 lb. Rate
LANTVB200 10" Tall, 200 lb. Rate
LANTVB220 10" Tall, 220 lb. Rate
LANTVB250 10" Tall, 250 lb. Rate
LANTVB260 10" Tall, 260 lb. Rate
LANTVB280 10" Tall, 280 lb. Rate
LANTVB300 10" Tall, 300 lb. Rate
ST Series Bump Stop Springs
Eliminate the problems commonly associated with bump stops. Manufactured from high tensile steel, ST Series bump stop springs feature a linear rate, which allows easier adjustability as the spring rate determines how hard you want to hit the stop, and how quickly. Simple calculations determine how much spring deflection is required to provide the desired load balance. Bump spring cups include a center bushing to reduce friction.
Free Outside Length Diameter
Part No. (in) (in)
Bump Springs Cups
Part No.
Bump Stop Cups
Part No.
Spring Rate (lbs/in)
Installed Height
Load @ Installed Height
Available Deflection (in)
LANST600
2.13"
1.96"
600
2.0"
95
1.00"
1.9"
155
1.8"
214
1.7"
273
1.6"
334
1.5"
402
1.4"
475
1.3"
549
1.2"
623
1.1"
700
Description
Description
LANBUMPCUP5/8
LANBUMPCUP14MM
14mm
LANBUMPCUP5/8
5/8"
LANBC345/14MM
14mm Bump Cup, 1/2", Over 2,500 lbs.
LANBC345/16MM
16mm Bump Cup, 5/8", Over 2,500 lbs.
256
2022-23 PARTS AND ACCESSORIES
