Page 392 - 2022-23 Auto Performance Open Wheel Catalog

SHR Flex Frontal Head Restraint
Designed with safety, comfort, and
ease of use in mind, the SHR Flex
is manufactured from high-strength
carbon-reinforced materials, while
maintaining an affordable price. The
frontal head restraint features an an-
gle-independent design and a small,
low collar that allows compatibility
with any seating angle. The floating
tether allows a full range of head mo-
tion to the left or right, while providing
increased side stability. The SHR Flex
meets SFI 38.1 specifications and is
sold complete with helmet posts that connect directly to the M6 nuts.
6-Point Harness Latch Link III-6H
Competition 6-point harness in-
cludes HANS specific 2"/3" shoul-
der belts, central latch system,
3" lap belts, and dual submarine
belts. Lap and shoulder belts include 3-bar slides for wrap-around style mounting. Meets SFI 16.1 specifications. Black only.
Part No.
Enduro 2X2
SRBSR94510-0-26
Description
SRBSR76560H
RH Pull-Down Adjust
SRBSR71760H
Double Pull-Up Adjust
Part No.
Latch Link III-5 SRBSR71750D Latch Link, 5-point competition harness is
complete with 3" shoulder belts, central latch system, 3" lap belts with double pull-up adjust and fixed sub strap. Lap and shoulder belts include 3-bar slides for wrap-around style mounting. Meets SFI 16.1 specifications.
Description
SRBSR42602A-SFI
Medium (Up to 16" Neck) with Pads
SRBSR42603A-SFI
Large (Over 16" Neck) with Pads
SRBSR00056-0
SHR Flex Helmet Hardware
5-Point Harness
Latch Link III-5H
Latch Link 5-point competition
harnesses include HANS specific
2"/3" shoulder belts, central latch
system, 3" lap belts, and sub strap. Meets stringent SFI 16.1 specifications. Lap and shoulder belts include 3-bar slides for wrap-around mounting. Black only.
Harness features FHR (Fron-
tal Head Restraint) specific 2" shoulder belts, 2" lap belts, and
a T-bar adjustable sub strap. All mounting points are wrapped in and may be retained by snap-in or bolt-in end fittings. Incorporated “ZIP Adjust- er” optimizes adjuster
positioning for eased
tightening and release.
Black only.
Competition Harness Pads
SRBSR09119
Pads provide cushioning be-
tween harness webbing and driv-
er’s shoulders, increasing comfort. Black with silver Schroth Racing logo. Sold as a pair. Note: Not compatible with HANS device.
Competition Harness Installation Hardware
Part No.
Description
SRBSR01324
Part No.
SRBSRB15
Description
SRBSRLV7NC
SRBSR01324
Rally End Kit with Bolts and Washers
SRBSRB15
Harness Hardware, Snap-In, 3" Wide, SFI 16.1/16.5, FIA Approved, Steel, Natural
SRBSRB23C
Bolt-In Bracket, Bendable
SRBSRLV10.A
Slide Adjuster, 3-Bar for 2" Belt
SRBSRLV4NC
Slide Adjuster, 2-Bar for 2" Belt
SRBSRLV7NC
Slide Adjuster, 3-Bar for 3" Belt
SRBSRSG22
Eye Bolt, 7/16" Dia. x 1.5" Long
SRBSRSG39
Reinforcement Plate with 7/16" Nut
Fixed Sub Belt
SRBSR71050H
LH Pull-Up Adjust
SRBSR71750H
Double Pull-Up Adjust
SRBSR76050H
LH Pull-Down Adjust
Adjustable Sub Belt
SRBSR76751H
Double Pull-Down Adjust
390
2022-23 PARTS AND ACCESSORIES
