Thermowell

Introduction

Thermowells are used for protecting temperature ■
Insertion
sensing elements from excessive pressure, from solid The distance from the end of the well to the underside of
particles in suspension or from aggressive fluids. the thread, or other connection means, (Designated as
Another advantage of thermowell is the possibility to "U") is the insertion length.
remove the temperature sensing instruments without
any risk of effecting the tightness of the enclosure and
■
without stopping the process. Bore size
Almost any installation uses several types of temperature
Selection of thermowell measuring instruments.
■ The selection of a standard bore diameter can produce
Material
In general, the thermowell material chosen for the extreme flexibility within the plant.
installation is governed mainly by the corrosion The bore size of thermowells is shown in this
conditions the thermowell will face. Catalogue Ordering Information.
Recommended materials for various services are
given in the corrosion table.
■
Occasionally, the material consideration is one of Tapered or straight
strength rather than corrosion. For example, a Tapered type thermowells provide greater stiffness for
stainless steel thermowell may be required for high the same sensitivity. The higher strength to weight ratio
pressure water service where otherwise a brass gives these thermowells higher natural frequency than
thermowell would be satisfactory from a corrosion for equivalent length straight type thermowells, thus
standpoint. permitting operation at higher fluid velocity.
