Capability
Pressure Instrument
Dial size - Min : 50mm, Max : 200mm or etc./ Range - Min : -0.1 MPa, Max : 200 MPa
Sun Shade Size : 230mm× 370mm×125mm / 410mm×350 ×170mm / Other
Temperature gauge
Dial Size : Min : 75mm, Max 150mm or etc. / Range – Min : - 50 , Max : 700
Temperature sensor
Length - Min : 50mm, Max : Unlimited / Range - Min : - 200 , Max : 1700
Thermowel l
Length - Min : 50mm, Max :10000mm or more than
Level Instrument
Length - Max. 5 m /Vessel connection - Max : 2” or more than) Length : 5m
Flow element
Out diameter -Max : 3 m / Length- Max :10m / Thickness – Max : 100 mm
Item Capability
Pressure Instrument 25,000 ea / month
Sun Shade 3,000 ea / month
15,000 ea / month
Temperature Instrument 1,000 ea / month
Flow and Level Instrument
