PENDANT LIGHTING CHANNEL
PENDANT LIGHTING CHANNEL

PALETTE IN PL 60 67.5 50 24.13 32.55 PALETTE IN PL PALETTE IN PL 60 67.5 50 24.13 32.55 PALETTE IN PL

60 23 49.1 39 60 23 49.1 39
27.7 Ⅲ 27.7 Ⅲ
49 49

FAMILY MODEL DIMENSION ACCESSORIES INSTALLATION FAMILY MODEL DIMENSION ACCESSORIES INSTALLATION
Ⅲ PL PENDANT LIGHTING 5068 1000mmX50mmX68mm AP ALUMINIUM PROFILE PT PENDANT Ⅲ PL PENDANT LIGHTING 5068 1000mmX50mmX68mm AP ALUMINIUM PROFILE PT PENDANT
SYSTEM
SYSTEM
PC
PC
PC COVER
PC COVER

FAMILY MODEL DIMENSION ACCESSORIES INSTALLATION S EDP STRING FAMILY MODEL DIMENSION ACCESSORIES INSTALLATION S EDP STRING
END CAPS (PLASTIC)
END CAPS (PLASTIC)
EDW END CAPS (SCREWS) EDW END CAPS (SCREWS)
PL PENDANT LIGHTING 6060 1000mmX60mmX60mm AP ALUMINIUM PROFILE PT PENDANT EXAMPLE: PL5068-1000mmX50mmX68mm-PT PL PENDANT LIGHTING 6060 1000mmX60mmX60mm AP ALUMINIUM PROFILE PT PENDANT EXAMPLE: PL5068-1000mmX50mmX68mm-PT
SYSTEM SYSTEM
PC PC COVER PC PC COVER
S STRING PL1060 S STRING PL1060
EDP END CAPS (PLASTIC) EDP END CAPS (PLASTIC)
PL6035 EDW END CAPS (SCREWS) EXAMPLE: PL6060-1000mmX60mmX60mm-PT PL6035 EDW END CAPS (SCREWS) EXAMPLE: PL6060-1000mmX60mmX60mm-PT
24.39 24.39
60 60
60 60
24.35 24.35
89 89
35 28.4 100 35 28.4 100
49.2 49.2
Ⅲ Ⅲ
Ⅲ Ⅲ

FAMILY MODEL DIMENSION ACCESSORIES INSTALLATION FAMILY MODEL DIMENSION ACCESSORIES INSTALLATION

FAMILY MODEL DIMENSION ACCESSORIES INSTALLATION PL PENDANT LIGHTING 1060 1000mmX100mmX60mm AP ALUMINIUM PROFILE PT PENDANT FAMILY MODEL DIMENSION ACCESSORIES INSTALLATION PL PENDANT LIGHTING 1060 1000mmX100mmX60mm AP ALUMINIUM PROFILE PT PENDANT
SYSTEM
SYSTEM
PC
PC
S PC COVER S PC COVER
STRING
STRING
PL PENDANT LIGHTING 6035 1000mmX60mmX35mm AP ALUMINIUM PROFILE PT PENDANT PL PENDANT LIGHTING 6035 1000mmX60mmX35mm AP ALUMINIUM PROFILE PT PENDANT
SYSTEM EDP END CAPS (PLASTIC) SYSTEM EDP END CAPS (PLASTIC)
PC PC COVER PC PC COVER
S STRING EDW END CAPS (SCREWS) S STRING EDW END CAPS (SCREWS)
EDP END CAPS (PLASTIC) EXAMPLE: PL1060-1000mmX100mmX60mm-PT EDP END CAPS (PLASTIC) EXAMPLE: PL1060-1000mmX100mmX60mm-PT
EDW END CAPS (SCREWS) PL3875 EDW END CAPS (SCREWS) PL3875
PL5022 EXAMPLE: PL6035-1000mmX60mmX35mm-PT PL5022 EXAMPLE: PL6035-1000mmX60mmX35mm-PT
35 35
26 26
27 27
5.5 12.2 5.5 12.2
73 73
22.7 27 28.2 27 Ø2.6 34.78 22.7 27 28.2 27 Ø2.6 34.78
Ø5.5
Ø5.5
150 31.2 150 31.2
Ⅲ Ⅲ Ⅲ Ⅲ

FAMILY MODEL DIMENSION ACCESSORIES INSTALLATION FAMILY MODEL DIMENSION ACCESSORIES INSTALLATION FAMILY MODEL DIMENSION ACCESSORIES INSTALLATION FAMILY MODEL DIMENSION ACCESSORIES INSTALLATION
PL PENDANT LIGHTING 5022 1000mmX150mmX22mm AP ALUMINIUM PROFILE PT PENDANT PL PENDANT LIGHTING 3875 1000mmX38mmX75mm AP ALUMINIUM PROFILE PT PENDANT PL PENDANT LIGHTING 5022 1000mmX150mmX22mm AP ALUMINIUM PROFILE PT PENDANT PL PENDANT LIGHTING 3875 1000mmX38mmX75mm AP ALUMINIUM PROFILE PT PENDANT
SYSTEM SYSTEM PC SYSTEM SYSTEM PC
PC PC COVER PC COVER PC PC COVER PC COVER
S STRING S STRING S STRING S STRING
EDP END CAPS (PLASTIC) EDP END CAPS (PLASTIC) EDP END CAPS (PLASTIC) EDP END CAPS (PLASTIC)
EDW END CAPS (SCREWS) EDW END CAPS (SCREWS) EDW END CAPS (SCREWS) EDW END CAPS (SCREWS)
EXAMPLE: PL5022-1000mmX150mmX22mm-PT EXAMPLE: PL3875-1000mmX38mmX75mm-PT EXAMPLE: PL5022-1000mmX150mmX22mm-PT EXAMPLE: PL3875-1000mmX38mmX75mm-PT
