Page 31 - Aspinall Associates, Inc. - Sloan Training Guide

CROSS

FIXTURE GUIDEREFERENCE

Description Sloan Model/Code American Standard Kohler Zurn

Hybrid & WaterFree Urinals

Standard Hybrid w/ JetRinse HYB-1000/1001020 NE NE NE
Standard Retrofit Hybrid w/ JetRinse HYB-1000-RET/1001021 NE NE NE

Small Hybrid w/ JetRinse HYB-4000/1004020 NE NE NE
Designer Hybrid w/ JetRinse HYB-7000/1007020 NE NE NE

Standard Waterfree WES-1000/1001000 Flowise - 6150.100 Steward - K4919 Z5795
Small Waterfree WES-4000/1004000 Flowise - 6155.100 Steward - K4918 NE
Designer Waterfree WES-7000/1007000 NE Steward - K4917 NE

Lavatories

Undermount Oval - 19 1/2" x 17 1/2" SS-3001/3873001 Ovalyn - 496.221 Caxton-K2210 Z5220
Drop-in Oval - 20" x 17" (Single) SS-3102/3873102 Aqualyn - 475.047 Pennington - K2196-1 Z5114

Drop-in Oval - 20" x 17" (4" CS) SS-3002/3873002 Aqualyn - 475.028 Penningto - K2196-4 Z5111
Drop-in Oval - 20" x 17" (8" CS) SS-3802/3873802 Aqualyn - 475.020 Pennington - K2196-8 Z5118
WH w/ Backsplash - 20 3/4" x 18 1/4" (Single) SS-3103/3873103 Lucerne - 356.421 Kingston - K2007 Z5341

WH w/ Backsplash - 20 3/4" x 18 1/4" (4" CS) SS-3003/3873003 Lucerne - 355.012 Kingston - K2005 Z5344
WH w/ Backsplash - 20 3/4" x 18 1/4" (8" CS) SS-3803/3873803 Lucerne - 355.015 Kingston - K2006 Z5348

WH ADA Ledgeback - 21" x 20 (Single) SS-3165/3873165 Murro - 955 Brenham - K1997-1 Z5351
WH ADA Ledgeback - 21" x 20"" (4" CS) SS-3065/3873065 Murro - 954 Brenham - K1997-4 Z5354
Ceramic Shroud SS-27-A/0387678 0059.020EC K-1998-0 N/A

SloanTec Hydrophobic Antimicrobial Glaze available on ALL fixtures. Just add -STG to the model number.
Contact Sloan for code numbers and combination package model numbers not listed.
