Circuit-Information of wire insert parts

B108 connect to chassis wire B110 connect to left floor wire
Terminal Terminal
Color Function Remarks Color Function Remarks
No. No.
Right front wheel Left door lamp
1 Black 1 Green
speed sensor switch
Right front wheel 2 Null
2 Brown
speed sensor 3 Null
Exhaust coil of right 4 Null
3 Blue front wheel solenoid Hand brake
5 R-Y
valve switch
Solenoid valve of 6 Null
4 Brown
right front wheel 7 Null
Right rear wheel 8 Null
5 Brown
speed sensor
Left rear wheel
6 Black
speed sensor
Left rear wheel
7 Brown
speed sensor
Solenoid valve of
8 Brown
right rear wheel
Solenoid valve of
9 Blue
left rear wheel
Solenoid valve of
10 Brown 61
left rear wheel
Right rear wheel
11 Black
speed sensor
Left front wheel
12 Black
speed sensor
Left front wheel
13 Brown
speed sensor
Solenoid valve of
14 Blue
right rear wheel
Solenoid valve of
15 Blue
left front wheel
Solenoid valve of
16 Brown
left front wheel
