Exercise
1 Draw a 3-bit parallel load register implemented on SR flip flops. Show how the bit stream 110 is
loaded at the input lines and how it simultaneously appears at the output lines
2 Use a 3-bit register implemented on D flip flops to show that the operation of serial load is equivalent
to shifting 1 bit to the right at a time.
3) Draw a 3- bit SIPO shift register and explain its operation using the bit stream 110
Lecture 18 Video Lecture
Watch the complete explanation of this chapter here:
Lecture 18 Online Quiz
Test your understanding by completing the quiz:
