THE CHAIR-CHECK II CONTROL UNIT

The Chair-Check II control unit is used in conjunction with a Bed-Check® Sensormat® pad
as a system to effectively monitor patients at risk of falling or residents in a bed, chair,
wheelchair, or on a toilet. Chair-Check II provides an audible alarm to alert the caregiver
when the person attempts to get up unassisted.
Product Description
• Control unit uses a 9V alkaline battery for a long usage life
• Secured battery containment discourages tampering
• Non-latching alarm allows monitoring to restart automatically when indi¬vidual’s
• weight is back on the Sensormat pad, and does not require caregiver intervention
• Monitor patient or resident in chair, toilet, wheelchair, or bed, using any Bed- Check®
• Sensormat® pad
• Configure Chair-Check II settings to the individual’s needs
• 2 volume settings, and a 0–5 second delay
• Assembled in the USA; Two-year limited warranty
Features and Operation
• The Chair-Check II is the most versatile control unit in Bed-Check’s product line.
• Monitoring begins automatically when the patient’s weight is placed on the Sensormat pad
• Caregiver can put the system on Hold while repositioning the patient
• Controls for hold, tone, and delay may be easily changed by the caregiver
• Multiple tones allow the unit to be distinguished from other alarms or other Chair-Check II monitors
• Low battery and charge alert. Secured battery access
• 9V battery or AC operation allows for use in portable or fixed applications
• Chair Check II features configurable delay settings
- Delay is 0 seconds for most seated applications, since the patient is postured for quick stand up.
- Delay is 1, 3, or 5 seconds may be set for other circumstances, such as bed monitoring
• Utilizes pressure-sensitive Sensormat pads available for chair, bed or toilet monitoring. Not intended for use with other
manufacturers’ pads
• The alarm ceases and monitoring automatically resumes (non latching) when weight is again sensed, reducing caregiver
intervention compared to string-activated alarms
• Conforms to UL® 1069 and CSA C22.2 No. 205R Standards

PRE-EMPTIVE PRESSURE SENSITIVE CHAIR SENSORMAT®

Bed-Check's exclusive heat-seal process bonds the Sensormat layers to greatly reduce the chance of
moisture penetration and prevent delamination. Mats are not susceptible to damage from cleaning solutions.

STANDARD BLUE VINYL CHAIR EXIT PAD

The Standard Vinyl Sensormat comes with a durable vinyl cover for easy cleaning.

CHAIR SENTINEL WHEELCHAIR ALARM

The patient-releasable seat belt alarm that monitors patient safety even when out of staff’s
view. The Chair Sentinel is a patient-releasable safety device. Releasing the belt causes a loud
alarm signal to alert your staff.

Product # 72010 Chair-Check II Control Unit
Product # 73011 Chair Pre-emptive - Pressure Sensitive Sensormat® 30 Day 10/Box
Product # 73011-5 Chair Pre-emptive - Pressure Sensitive Sensormat® 90 Day 5/Box
Product # 93010 Standard Chair Sensor Pad - 45 Day
Product # 93020 Standard Chair Sensor Pad - 180 Day
Product # R-7800 Chair Sentinel With on/off switch
Product # R-7810 Chair Sentinel Without on/off switch
