Ru č na presa za podmazivanje

Sa uvinutom metalnom cijevnom sapnicom
4-struka obloga za istiskanje masti
za mast u rifuzi ili 400 g kartuše (prema DIN 1284)
Metalna sapnica nalazi se u ručci za lakši transport

Artikel-Nr. Artikel-Bezeichnung
Ručna presa za podmazivanje
2909 1

Obujmice FÖRCH W2

DIN: 3017
Materijal ku iata: Nehr aju i elik
Materijal vijka:
elik
Materijal trake: Nehr aju i elik
Tip pogona: Vanjski aesterokut, Dugi prihvat
(LS), Krini prihvat Phillipps (PH)
Me unarodni standardi (Norme): AISI/AS 304,
SS 2320, SUS 430, BS 430 S 17

Artikl-Br. airina trake Stez.podru
je VL VPE
vrsto a trake Moment pritezanja
(BB) mm (SB) mm mm (S) mm Nm
3250 8 12 7,5 8,0 3 12,0 7 100 0,60 5,0
3250 8 16 7,5 8,0 3 16,0 7 100 0,60 5,0
3250 10 16 9,0 10,0 3 16,0 7 100 0,65 5,0

3250 12 20 9,0 12,0 3 20,0 7 100 0,65 5,0
3250 16 25 9,0 16,0 3 25,0 7 100 0,65 5,0
3250 20 32 9,0 20,0 3 32,0 7 100 0,65 5,0
3250 23 35 9,0 23,0 3 35,0 7 100 0,65 5,0
3250 25 40 9,0 25,0 3 40,0 7 100 0,65 5,0
3250 32 50 9,0 32,0 3 50,0 7 50 0,65 5,0
3250 40 60 9,0 40,0 3 60,0 7 50 0,65 5,0
3250 50 70 9,0 50,0 3 70,0 7 25 0,65 5,0
3250 60 80 9,0 60,0 3 80,0 7 25 0,65 5,0
3250 70 90 9,0 70,0 3 90,0 7 25 0,65 5,0
3250 80 100 9,0 80,0 3 100,0 7 25 0,65 5,0
3250 90 110 9,0 90,0 3 110,0 7 25 0,65 5,0
