Push / Pull / Transport

DR Series ●Micromovement and High Positioning Accuracy

●Compact, Space Saving
Wide Table Type Table Type

DR Series: with AZ Series
Frame Size (mm) 20 / 28 / 42 / 60 Rod Type with Guide Rod Type
Max. Speed (mm/s) 200
Encoder
Max. Transportable Mass - Vertical (kg) 50
(Battery-free Absolute
Max. Transportable Mass - Horizontal (kg) 50 Ball Screw Nut Hollow Rotor Sensor)
Max. Thrust Force (N) 500 Joint Ball Screw Shaft Guide
Repetitive Positioning Accuracy (mm) ±0.003/±0.005/±0.01
Stroke Length (mm) 25∼50
Brake / Guide / Knob / Ball Screw
Options
Cover / Installation Plate
Power Supply VDC 24/48
Starting From (Actuator+Driver+Cable) $1,196.00
Large-Diameter Bearing
Supports the axial load directly
A ball screw nut and a hollow rotor are connected directly
Gripping

EH Series ●Small and Light Weight
48.5 mm
91 mm

46 mm

EH Series: with AZ Series
Maximum Grip Force (N) 25
Stroke 25 mm
Repetitive Positioning Accuracy (mm) each side ±0.02

●High Reliability, Closed Loop Control
Backlash (mm) each side 0.1
Stroke (mm) 25 (12.5 each side)
Maximum Speed (mm/s) 156 (78 each side)
Push Speed (mm/s) 20 (10 each side) Rack
Minimum Travel Amount (mm) 0.02 (0.01 each side)
Permissble Load (N) 5
Base Jaw
Static Permissble Moment (N·m) MP:1.2 MY:0.12 MR: 0.4
Power Supply VDC 24/48
Battery-Free Absolute Sensor
Starting From (Actuator+Driver+Cable) $1,297.00 Base Jaw
(ABZO Sensor)
Pinion
Linear Motion / High Power

L Series L Series: with AZ Series ●Compact and High Strength
Frame Size (mm) 60/80
Max. Speed (mm/s) 500 Rack
100 (20 mm/s)
Max. Transportable Mass (kg) Rack Grommet
70 (40 mm/s)
1008 (20 mm/s)
Max. Thrust Force (N)
705 (40 mm/s)
Motor
Max. Stroke Length (mm) 1000
Type Horizontal / Vertical Gear
Option Brake Rack case
VDC 24/48 Pinion gear
Power Supply Single-Phase (VAC) 100-120, 200-240
Three-Phase (VAC) 200-240
Starting From (Actuator+Driver+Cable) $1,328.00
