Page 277 - E-Book Product Assembly For C02 Robot
P. 277
MAGNION FURNITURE INDUSTRIES
HOLE CODE NUMBER
DATE HOLE - A HOLE - B HOLE - C HOLE - D
J14 - 11 J14 - 38 J14 - 44 J14 - 17
ROBOT - 4 B
A
B C
D
A D
C
PD31 - 5
NO REVISION DRN CHKD DATE M.Faidz QUANTITY : 1 SET
DRAWN : DRAWING AJPD315 - 388 - 000 - 00
NO
13/6/2022
MATERIAL : SS400
PART PEDESTAL DESK - 3 DRAWER RHS
APPROVED :
SURFACE SELF COLOUR NAME W42'' x D24 x H30'' x 1''(OVERLAY)
TREATMENT :
3RD ANGLE PROJECTION MODEL URBAN - PEDESTAL DESK
SCALE : NTS
