ROG AURA Terminal

Four-port addressable RGB controller with ROG Halo and
Aura Sync
• ROG Halo: Enables ambient RGB synchronization to reflect
in-game action when LED strips are mounted behind the monitor
Motherboards
Motherboards
• Synchronize lighting with Aura Sync addressable gear for stunning
PC gaming illumination
• Illuminated ROG logo: Four built-in Aura lighting effects

SPECIFICATIONS

Exclusive Features • Aura Software support - Processor: 6 th Generation Intel® Core TM i5 or above/

• Halo Software support AMD 1 st Generation Ryzen 5 or above
• 4 built-in lighting effects - Graphics: NVIDIA® GeForce® GTX 900 series and later/

Dimension • W 70 x L 100 x H 20mm AMD Radeon R9 series and later

Input • USB 2.0 connection for data: Package contents • 1 x manual

- USB 2.0 9-pin header cable for internal case lighting • 2 x 30cm ROG addressable RGB strips
- USB 2.0 Type-A cable for external case lighting • 1 x 60cm ROG addressable RGB strip
• 12V/19V DC input for power: • 3 x extension cables
- 12V 4-pin molex to DC adapter cable for internal case lighting • 1 x 45W power adapter
- 19V DC power adapter for external case lighting • 1 x DC to MOLEX cable

Output • 4 channel addressable RGB* • 1 x Micro USB to USB 2.0 Type-A data cable
Graphics Cards & PSUS
Graphics Cards & PSUS
* Each channel with a max of 90 LEDs and total channels • 1 x Micro USB to 9-pin header data cable

support a max of 210 LEDs. • 3 x packs of 3M double-sided tape (5cm)

Hardware • PSU with a free Molex socket • 1 x ROG stickers

Requirements • PC with a free USB port or free USB 2.0 header • 2 x ROG cable ties
Recommended
System - OS: Windows® 10 64-bit Note: The specifications are subject to changes without notice.
Requirements • Halo:

- OS: Windows® 10 64-bit
ROG Spotlight
• AURA: Display
Display
ROG Spotlight USB logo projector with
Aura Sync RGB LED Networks
• Synchronize lighting with ASUS Aura
Sync-enabled gear to perfectly illuminate
Networks
your battlestation
• 360-degree lens adjustment, ensuring the
ROG logo is always positioned upright
• Magnetic base for easy attachment to any
metal surface ODD & Storage

SPECIFICATIONS
Dimension • 50 x 54 x 30.2mm Rotation • 360°
Project distance • 20-100cm Mounting solution • Magnetic base
ODD & Storage
Weight • 123g Software support • ROG Aura
Interface • USB type
LED • RGB 3535 LED Note: The specifications are subject to change without notice.
Power in • +5V
ROG Addressable
LED Strip
ROG Addressable LED Strip with magnetic backing and
Aura Sync RGB - 30 & 60cm
Server & Workstation
Server & Workstation
• High-brightness addressable RGB strip with individually
programmable LEDs
• Magnetic backing for easy attachment to metal surface, and a
3M™ DIY kit with double-sided tape for other surfaces
• Synchronize lighting with Aura Sync gear via 3-pin addressable
RGB headers on motherboards for infinite lighting possibilities
Mini / Stick PC
Mini / Stick PC

SPECIFICATIONS
LED Type • RGB 5050 LED Beam Angle • 120°
LED QTY • 60cm: 30 PCS PCBA color • Black
• 30cm: 15 PCS Dimension • 60cm: Length 600mm x Width 10 x Thickness 2 mm
Operating Voltage • 5V • 30cm: Length 300mm x Width 10 x Thickness 2 mm
Power Consumption • 9W Accessories • 1 x ASUS addressable header extension cable
*Product specifications are subject to change without notice, although every effort is made to ensure that they are correct up to the point of launch.
Operating Temperature • -30°C-+90°C • 6 x 3M double-coated tape 5cm
Please contact your suppliers or local dealers for exact product launch schedules, specifications and availability.
Adhesive Solution • Magnetic
Peripherals
Peripherals
• 3M double-coated tape (optional)
