Superior performance cast machine film

with one-sided cling

Equipment Targets for Replacement

• Overhead straddle, turntable, or both • Transcend 47–55 ga films—replacing
• Recommended RPM range: all commodity-type films of 70–80 ga
• Transcend 40 ga—replace high performance
• Optimal pre-stretch range: 200%, up to 300%
(thickness and application dependent) 45–60 ga films
Product Offering Grid

JDE Number Product Code Gauge (mil) Width (in) Length (ft) Pounds per Roll Rolls per Pallet
1473704 TSD1022011500 40 20 11,500 36.80 40
1473631 TSD1023011500 40 30 11,500 55.20 20
1473632 TSD119209750 47 20 9,750 36.66 40
1473633 TSD119309750 47 30 9,750 55.00 20
1473723 XTSD127207500 50 20 7,500 30.00 40
1473634 TSD140208350 55 20 8,350 36.74 40
1473635 TSD140308350 55 30 8,350 55.11 20
1557389 TSD165207000 65 20 7,000 36.40 40
1557391 TSD165307000 65 30 7,000 54.60 20
1557396 TSD203205500 80 20 5,500 35.20 40
1557398 TSD203305500 80 30 5,500 52.80 20

Contact your sales representative for pricing.
For more information call us at
1.877.662.3779 or visit berryglobal.com

Transcend™ and MAC™ are trademarks of
Berry Global, Inc. or one of its affiliates.
