Catalog 0750-3 US P31, P32, P33 Series
Global Air Preparation System Manifold Blocks

Manifold Blocks Symbol

Features
• Available in 1/4" or 3/4" threaded inlet / outlet ports
• Two additional top and bottom auxiliary ports standard
• Can be mounted anywhere in the FRL system

Ordering Information Specifications

Auxiliary Auxilliary Operating temperature -40°C to 65.5°C (-40°F to 150°F)
Model In / Out port size port size Thread
type port size top bottom type Part number Max. supply pressure 20.7 bar (300 psig)
P31 1/4" 1/4" 1/4" NPT P31MA92022N Weight P31: 0.19 kg (0.26 lbs)
P33: 0.34 kg (0.42 lbs)
P32 1/2" 1/4" 1/2" NPT P32MA94024N
P33 3/4" 1/4" 1/2" NPT P33MA96024N
For thread type: BSPP 1
BSPT 2
NPT 9

Material Specifications
Body Aluminum

Dimensions mm (inches)

P31 P32 P33
Outlet Port
Top Port 3/4"
1/4"
Outlet Port
Top Port 1/2" Inlet Port 73
1/4" 3/4" (2.88)
Inlet Port
20 42 1/2" 60 36.5
(0.79) (1.66) (2.36) (1.44)
40 Top & 33
23.9
30
Inlet Outlet (1.58) Bottom (.94) (1.18) 66 (1.30)
Port Port Aux. Ports 47.8 (2.60)
1/4" FLOW 1/4" 19 1/4" (1.88)
(0.74) 23.9
41 40 47.8 (0.94) 47.8
(1.61) (1.58) (1.88) (1.88)
23.9
(.94)
Bottom Port
1/2"
Bottom Port
1/2"

79 Parker Hannifin Corporation
Pneumatic Division
Richland, Michigan
www.parker.com/globalfrl
