Lathe Tooling

Hardened and Ground
BORING & TURNING
Bullnose Live Centers Live Center Sets with seven Inserts
• Designed to hold pipe and hollow work. The body of these sets are constructed similar to Series
• Preloaded bearings to achieve good 312 Live Centers, however, for versatility the bodies are
thrust and radial capacities. provided with the following seven interchangeable inserts: BORING & TURNING
• Head made from heat treated hardened • 2 large male centers
high carbon alloy steel. • 1 female center
Morse Small Large Tool No. Price • 3 smaller, different sized male centers
Taper End End Each • 1 bullnose center
2 1/2 2-7/16 LA600-2 94.64
3 3/4 3 LA600-3 159.64
3 1-1/4 4 LA600-3A 171.44 Morse Taper Model No. Price
3 1-1/2 5 LA600-3B 240.64 Each
4 1-3/8 5 LA600-4 236.00 2 LASET-2 177.75
4 2 6 LA600-4A 276.96 3 LASET-3 182.25
5 1-3/8 6 LA600-5 313.92 4 LASET-4 201.15
5 2-1/8 8 LA600-5A 807.20 5* LASET-5 304.12
*Supplied with three inserts only.

Lathe Mandrels
Made of hardened steel and accurately ground to size. Designed for
setting up accurately bored or reamed blanks and castings for pulleys,
handwheels or hubs on centers, so that the outside diameter can be
turned concentrically with the axis of the hole in which the mandrel is fixed.
Size Overall Tool No. Price Size Overall Tool No. Price Size Overall Tool No. Price
Length
Length
Each
Each
Length
Each
1/8 2-1/2 LM4 7.09 23/32 6 LM23 12.94 1-1/4 8 LM40 25.94
5/32 3 LM5 7.74 47/64 6 LM23A 14.24 1-17/64 8 LM40A 31.85
3/16 3 LM6 7.74 3/4 6 LM24 12.94 1-9/32 8 LM41 31.85
7/32 3-3/4 LM7 8.45 49/64 6 LM24A 14.23 1-5/16 8-1/4 LM42 31.85
1/4 3-3/4 LM8 8.45 25/32 6-1/4 LM25 16.25 1-11/32 8-1/4 LM43 31.85
9/32 4 LM9 8.78 51/64 6 LM25A 17.88 1-3/8 8-1/2 LM44 31.85
5/16 4 LM10 8.78 13/16 6-1/4 LM26 16.25 1-13/32 8-1/2 LM45 37.05
11/32 4-1/4 LM11 9.04 53/64 6-1/4 LM26A 17.88 1-7/16 8-3/4 LM46 37.05
3/8 4-1/4 LM12 9.04 27/32 6-1/2 LM27 16.25 1-15/32 8-3/4 LM47 40.76
13/32 4-1/2 LM13 9.75 55/64 6-1/2 LM27A 17.88 1-1/2 9 LM48 37.05
7/16 4-1/2 LM14 9.75 7/8 6-1/2 LM28 16.25 1-9/16 9-1/4 LM50 41.93
29/64 4-1/2 LM14A 10.72 57/64 6-1/2 LM28A 17.88 1-5/8 9-1/2 LM52 41.93
15/32 5 LM15 11.05 29/32 6-3/4 LM29 17.88 1-11/16 9-3/4 LM54 47.45
31/64 5 LM15A 12.16 59/64 6-3/4 LM29A 19.67 1-3/4 10 LM56 47.45
1/2 5 LM16 11.05 15/16 6-3/4 LM30 17.88 1-13/16 10-1/4 LM58 54.28
33/64 5 LM16A 12.16 61/64 6-3/4 LM30A 19.67 1-7/8 10-1/2 LM60 54.28
17/32 5-1/4 LM17 12.48 31/32 7 LM31 17.88 1-15/16 10-3/4 LM62 59.15
35/64 5 LM17A 13.73 63/64 6-3/4 LM31A 19.67 2 11 LM64 59.15
9/16 5-1/4 LM18 12.48 1 7 LM32 17.88 2-1/8 11-1/2 LM68 64.68
37/64 5-1/4 LM18A 13.73 1-1/32 7 LM33 22.43 2-1/4 12 LM72 72.48
19/32 5-1/2 LM19 12.48 1-1/16 7-1/4 LM34 22.43 2-3/8 12 LM76 77.68
5/8 5-1/2 LM20 12.48 1-3/32 7-1/4 LM35 24.00 2-1/2 12-1/2 LM82 87.10
21/32 5-3/4 LM21 12.94 1-1/8 7-1/2 LM36 22.43 2-5/8 12-1/2 LM84 101.40
43/64 5-1/2 LM21A 14.24 1-5/32 7-3/4 LM37 24.00 2-3/4 13 LM88 110.50
11/16 5-3/4 LM22 12.94 1-3/16 7-3/4 LM38 25.94 2-7/8 13 LM92 115.70
45/64 5-3/4 LM22A 14.24 1-7/32 7-1/2 LM39 28.53 3 13 LM96 128.70

Expanding Mandrels
Center holes are ground and lapped. Automatic expansion feature
can be utilized on any bore within the range of the mandrel. Sets Size Pieces Set No. Price
Sizes up to 1" furnished with one sleeve, over 1" two sleeves. 1/2 to 1" 5 LME100 466.70
Size Length Length Sleeves Tool Price Size Length Length Sleeves Tool Price
Range of Arbor of Sleeve Furnished No. Each Range of Arbor of Sleeve Furnished No. Each
1/2 - 9/16 5 2-1/2 1 LME1 71.50 1 - 1-1/4 9 4 2 LME6 206.70
9/16 - 21/32 6 2-3/4 1 LME2 89.70 1-1/4 - 1-1/2 9 4 2 LME7 220.35
21/32 - 3/4 7 2-3/4 1 LME3 93.60 1-1/2 - 2 11-1/2 5 2 LME8 240.50
3/4 - 7/8 7 3-1/4 1 LME4 109.20 2 - 2-3/4 14 6 2 LME9 576.24
7/8 - 1 7 3-1/4 1 LME5 116.35 2-3/4-3-3/4 17 7 2 LME10 735.98
