ELECTROnIC IndICaTOR • Automatic Reversing
dIaL TEST IndICaTORS

Precision Tools Resolution : 0.0005” / 0.01mm • Satin Chrome Finish
Range : 0 - .5” / 0 - 12.7mm
• Adjustable Bezel
Functions include:
• Three-way
in/mm conversion, zero-set.
Dovetail mounting
• Carbide point
• 5/32” and 3/8”
Price
Order No.

mounting stems
Horizontal
• Fitted case
122.50
PR7250102

Dial Order Vertical
Range Grad. Reading Type No. Price
.030” .0005” 0 - 15 - 0 PR2198000 42.50
ELECTROnIC IndICaTORS .030” .0005” 0 - 15 - 0 Horizontal PR2198005* 42.50
.008” .0001” 0 - 4 - 0 PR2198010 65.50
0.8mm 0.01mm 0 - 40 - 0 PR2198030 51.40
featureS: .030” .0005” 0 - 15 -0 Vertical PR2198020 50.50
• Zero setting at any position 0.8mm .0.01mm 0 - 40 - 0 PR2198040 77.90
• Auto power on/off * Black Dial Face
• Data output
• Metric/Inch system conversion at any position

dIGITaL TEST IndICaTOR

• Power on / off key, Zero setting key,
Inch / Metric key, Tolerance key.
• Contact Point Diameter:
1
7250104 7250107 7250105 /8” / 2.5mm
7250106 • Accuracy: ± 0.001” / 0.02mm
range: ± 0.02” / 0.5mm
Range Resolution Order No Price
grad.: 0.0005” / 0.01mm
0 - 0.4” / 0 - 10mm .0005” / 0.01mm PR7250104 95.50
0 - 1.2” / 0 - 30mm .0005” / 0.01mm PR7250105 144.50
0 - 2” / 0 - 50mm .0005” / 0.01mm PR 7250106 174.20 Order No. Price
0 - .6” / 0 - 15mm .00005” / 0.001mm PR7250107 123.20
PR2190010 210.00

CEnTERInG IndICaTOR
Supplied complete with:
restraining rod, center point
feeler, 4” straight feeler, 8”
straight feeler, 12” straight
feeler, 4” curved feeler,
8” curved feeler, 12” curved
feeler, fitted case INCH

Specifications Order No. Price
• Designed for quick and accurate centering of a 6 /8”
Length:
7
work piace or fixture. Shank: /8”dia. x /8” long
7
3
• Operates at any angle. Probe ball: /8” diameter
1
• Use on vertical and horizontal machines Measuring range: .250 axis offset
• Use for internal and external diameters. Capacity: Internal: /32” to 4¼” dia. PR2190005 120.00
5
• While spindle rotates, the centering indicator remains External: 0 - 4¼” dia.
stationary and always faces the operator
Speed: Not exceed 800RPM Approx.
Locating accuracy To within 0.00025” of true center
Graduation: 0.0005”
