National Electrical Price Guide

Assemblies
Feeder EMT & Wire D/C SetScrew Coup, Strap, Screw & 1-1/2" EMT w/Pull Wire
Anchor
Qty Description Labor Cost Retail
10 1-1/2" EMT .60 23.27 38.48
12 Solid Pull Wire .04 .61 2.00
1 Average Fastener .01 .18 .40
1 8-10 x 7/8" Bantam Screw Anchor .06 .03 .07
1 1-1/2" EMT Cast Set Screw Coupling .06 1.36 5.50
1 1-1/2" EMT 1 Hole Steel Strap .04 .26 1.85
.81 $25.70 $48.29
Feeder EMT & Wire D/C SetScrew Coup, Strap, Screw & 1-1/4" EMT 2#1, 1#6
Anchor

Qty Description Labor Cost Retail
10 1-1/4" EMT .50 19.02 31.21
12 #6 THHN Stranded Copper .08 4.58 14.19
23 #1 THHN Stranded Copper .25 26.02 85.41
1 Average Fastener .01 .18 .40
1 8-10 x 7/8" Bantam Screw Anchor .06 .03 .07
1 1-1/4" EMT 1 Hole Steel Strap .04 .17 1.20
1 1-1/4" EMT Cast Set Screw Coupling .04 .97 3.65
.99 $50.97 $136.13
Feeder EMT & Wire D/C SetScrew Coup, Strap, Screw & 1-1/4" EMT 2#2, 1#8
Anchor
Qty Description Labor Cost Retail
10 1-1/4" EMT .50 19.02 31.21
12 #8 THHN Stranded Copper .07 2.98 9.26
23 #2 THHN Stranded Copper .23 20.74 67.56
1 Average Fastener .01 .18 .40
1 8-10 x 7/8" Bantam Screw Anchor .06 .03 .07
1 1-1/4" EMT 1 Hole Steel Strap .04 .17 1.20
1 1-1/4" EMT Cast Set Screw Coupling .04 .97 3.65
.95 $44.09 $113.34
Feeder EMT & Wire D/C SetScrew Coup, Strap, Screw & 1-1/4" EMT 2#3, 1#8
Anchor
Qty Description Labor Cost Retail
10 1-1/4" EMT .50 19.02 31.21
23 #3 THHN Stranded Copper .18 16.57 53.76
12 #8 THHN Stranded Copper .07 2.98 9.26
1 Average Fastener .01 .18 .40
1 8-10 x 7/8" Bantam Screw Anchor .06 .03 .07
1 1-1/4" EMT Cast Set Screw Coupling .04 .97 3.65
1 1-1/4" EMT 1 Hole Steel Strap .04 .17 1.20
.91 $39.92 $99.55
Feeder EMT & Wire D/C SetScrew Coup, Strap, Screw & 1-1/4" EMT 3#1
Anchor
Qty Description Labor Cost Retail
10 1-1/4" EMT .50 19.02 31.21
35 #1 THHN Stranded Copper .39 39.60 129.98
1 Average Fastener .01 .18 .40
1 8-10 x 7/8" Bantam Screw Anchor .06 .03 .07
1 1-1/4" EMT 1 Hole Steel Strap .04 .17 1.20
1 1-1/4" EMT Cast Set Screw Coupling .04 .97 3.65
1.04 $59.97 $166.51

ASSEMBLIES CONTAINING CONDUIT ARE BASED ON 10' LENGTHS
COST COLUMN IS A NATIONAL AVERAGE AND SHOULD BE VERIFIED FOR YOUR AREA
COPYRIGHT @ 1996-2019 by ELECTRICAL RESOURCES, INC.
