FAN-PEDIA PROPELLERS
Published by AEROVENT.COM
Aerovent OVERVIEW
©2017

“M” Propeller

RH ROTATION
ADJUSTABLE PITCH PROPELLERS Propeller Overview
SIZES 54” – 144” • Available in 2, 4 or 6 blades (M2, M4, M6)
• Narrower blades for quiet operation
Rotation: RH & LH • Macheta® tipped blades. Macheta® is Aerovent’s
trademark in the fan industry

Adjustable Propeller
• Hubs are pitch marked for blade settings from
10-50 degrees in 2 degree increments.
• 319 Aluminum (Standard)
• Fiberglass (Optional - see fiberglass prop section)
• Specialty coatings available
ROUNDED EDGE IS THE LEADING
EDGE OF THE BLADE FOR BOTH Fixed Propeller
RH & LH ROTATIONS • 319 Aluminum (Standard)
• A240 Aluminum (Optional)
> High temperature - up to 600 F
o
• Dura-Metal (Aluminum Bronze) (Optional)
> High temperature - up to 600 F
o
• Specialty coatings available
Airflow Direction & Rotation
RH ROTATION • Both adjustable and fixed props can be provided
FIXED PITCH PROPELLERS (CAST) in a LH & RH rotation and can be standard or
reverse bored for opposite airflow direction.
SIZES 9” – 48” • See Fixed & Adjustable Type - Rotation & Airflow
Rotation: RH & LH Section for additional details

See Adjustable Type Propellers - Rotation & Airflow
Section for additional information

40
