FAN-PEDIA ARRANGEMENTS
Published by
Twin City Fan & Blower Plug Fans
©2017 TCF.COM
Arrangement 1P Arrangement 4 Arrangement 4P
Belt Drive - Pedestal Plug Direct Drive Direct Drive - Pedestal Plug
Motor Mounted on Floor or Fan Base Wheel Mounted to Motor Shaft Wheel Mounted to Motor Shaft
Fan is floor mounted Fan is wall mounted Fan is floor mounted
Coupling
Coupling
Arrangement 8 Arrangement 8P
Direct Drive Direct Drive - Pedestal Plug
Motor Coupled to Fan Shaft Motor Coupled to Fan Shaft
Fan is wall mounted Fan is floor mounted
