P. 123
®
FAN-PEDIA MOTOR POSITIONS &
Published by AEROVENT.COM
Aerovent DISCHARGES
©2017
Vertical Configurations
INLINE CENTRIFUGAL | MIXED FLOW | AXIAL
Motor Positions (Arrangement 9 Only)
Duct Mount
Roof Mounted Floor Mount Ceiling Mount (no support Brackets)
No specified motor position for this configuration. No specified motor position for this configuration. Motor is centered
Motor is centered on curb cap as shown. between support brackets as shown.
Standard
F1 F2
Conduit Boxes
viewed from drive side of motor
(looking at motor shaft)
62
