 FAN-PEDIA                                                                                            SHAFT SEALS
 Published by   AEROVENT.COM
 Aerovent
 ©2017





                                                             V-Ring Type Shaft Seal

 Mounting Surface                                            Also Known As:
 (Typically Fan Housing)
                                                             - Axial Shaft Seal
                                                             - Teflon Shaft Seal / Teflon Style
 Shaft
                                                             Mounting Hardware
                                                             Mounting Studs (bolts welded inside housing),
                                                             Washers, Nuts






















                                                                                              Teflon Plate


                                                                                              Chekseal


                                                                                              PTFE Joint Sealant
