MODELLING AND SIMULATION OF SUPERELASTIC RING SPRINGS universal battery charger. He has got the PhD title at the School of “High
FOR HIGH ENERGY DISSIPATION Mechanics and Automotive Design & Technology”, in the course of
Modelling and Mechanical Design Methods in 2010. Andrea has an
ongoing collaboration with the University of Monterrey, Mexico about
Andrea Spaggiari magnetorheological fluid system design and previously he was hosted at
University of Modena and Reggio Emilia the Materials & Surface Science Institute at Limerick University, Ireland,
Modena MO, Italy working on multiscale modeling of void polymers. He established a
collaboration between the institutions which is still going on. From 2011
Andrea works as assistant professor at the University of Modena and
Reggio Emilia and he is the lecturer of the academic course of “New
Materials for Mechatronics Constructions” in the Master course of
Abstract
Mechatronic Engineering and “Integrated 3D Modelling for Mechatronic
The present work analyzes the behavior of the ring springs rings made of
design” in the course of Mechatronic Engineering. His current research
superelastic materials, typically Nickel Titanium alloys, but not limited to
interests are threefold. First he continues to develop the topic of his PhD,
this specific alloy. Classical ring springs are mechanical elements used in
studying the properties and the mechanical behaviour of structural
many industrial applications and in transport for shock absorption and
adhesives and their efficient modelling. Second he is working on
energy dissipation. They are constituted by a stack of internal and external
magneto-rheological fluids fundamental research and applications with an
metal rings (typically made of high strength steel), with tapered surfaces in
ongoing project in collaboration with a world leader company in automo-
contact with one another. Under the action of an axial load these surfaces
tive high performance brakes. Third, he works on shape memory alloys,
slide, the rings are deformed circumferentially and energy is dissipated
mainly for actuator design and development.
due to friction. Often lubricant is present between the rings to limit wear of
the rings, but in this analysis is not considered. The main advantages of
these springs are the high specific energy stored and the large damping
capacity due to sliding friction. Furthermore, the stiffness and damping are
independent on the strain rate and the temperature, which limits or avoids
the occurrence any resonance problems. The superelastic materials
considered is characterized by a stress plateau almost constant and large
reversible deformations. It can be used to replace traditional steels in ring
springs, which gives a significant performance. Compared to the tradition-

al steel version where energy is dissipated only due to friction, if almost
one of the inner or the outer rings is made of superelastic material there is
an increase of the dissipated energy thanks to the internal hysteresis of
the material. The work studies analytically, through simplified mechanical
14
models, the ring springs in traditional material and in superelastic material,
providing useful equations to dimension these mechanical elements,
