P. 265
Screwdrivers
Pipe socket spanners
Cranked box spanner
Hollow form, curved
Execution:
With identical wrench sizes Technical Data:
Can also be used with plug-in tommy bar Surface: Chrome-plated
Advantage: Material: Chrome-vanadium steel
The hollow shape allows deep screws and nuts to
be tightened/loosened
Width across flats 6 mm 7 mm 8 mm 9 mm 10 mm 11 mm 12 mm 13 mm
Length (mm) 105 110 115 122 130 136 145 152
Hole Ø of mount (mm) 6 6 6 6 8 8 8 8
Head Ø (mm) 10 12 13 14 15.5 16.5 18 19.5
513
512
506
511
510
507
509
Ident. No.
52183... Unit price, € O. R. O. R. 508 O. R. O. R. O. R. O. R. O. R.
O. R.
Width across flats 14 mm 15 mm 16 mm 17 mm 18 mm 19 mm 21 mm 22 mm
Length (mm) 160 170 178 187 195 205 225 230
Hole Ø of mount (mm) 10 10 12 12 12 14 14 14
Head Ø (mm) 21 22.5 24 25.5 26.5 28 32 32
515
517
522
518
519
Ident. No.
521
514
52183... Unit price, € O. R. O. R. 516 O. R. O. R. O. R. O. R. O. R.
O. R.
Width across flats 24 mm 27 mm 30 mm 32 mm
Length (mm) 250 280 310 330
Hole Ø of mount (mm) 18 20 20 20
Head Ø (mm) 30.3 38 42 45
532
524
Ident. No.
527
52183... Unit price, € O. R. O. R. 530 O. R.
O. R.
Prod. Gr. 526
General tools
www.buypremiumtools.com 265
