VARO Shelving and Stocking System, Workshop Lorries, Assortments, Vehicle Modules

Modular package I:

Installation Driver’s side: Installation Passenger’s side:
Rechts (Beifahrerseite):
Links (Fahrerseite):

Module 64 – 80 Module 44 – 80 Module 64 – 80
Width: 1.488 mm Width: 949 mm

Height:
1.386 mm

(PT = partial thread)
Depth370 mm (PT = partial thread)

Basis block Weight Basis block Weight
Basic module: Art. No. 9009 64 80 1 approx 34 kg Basic module: Art. No. 9009 64 80 1 approx 34 kg
Premium module: Art. No. 9009 64 80 3 approx 42 kg Premium module: Art. No. 9009 64 80 3 approx 42 kg
Expansion module Weight
(PT = partial thread)
Basic module: Art. No. 9009 44 80 2 approx 24 kg
Premium module: Art. No. 9009 44 80 4 approx 30 kg
Select your individual modular equipment:
Basic module or premium module (incl. drawer and shelf flap)
You can add further drawers and shelf flaps in different heights, as well as more shelfs and shelf tank bottoms to your vehicle equipment
(see accessories from Page 18/890).
Floors and side panels:
For standard vans (without a window, bench, separating grid, etc. in the cargo space)

Model from Model Wheelbase Excess Drive type Height Art. No. of floor Art. No. of side Image No.
length panel
Ford Transit 2014 3.300 mm – Front Normal 9011 1000002680 9011 1000002687 1 – 6
Ford Transit 2014 3.300 mm – Rear Normal 9011 1000002873 9011 1000002687 1 – 6
Iveco Daily 2014 3.520 mm – Front Medium 9011 1000002757 – –
MAN TGE 2016 3.640 mm – Front Normal 9011 1000005278 – –
MAN TGE 2016 3.640 mm – Front Medium – – –
MAN TGE 2016 3.640 mm – Rear Normal – – –
VW Crafter 2016 3.640 mm – Front Normal 9011 1000005278 – –
VW Crafter 2016 3.640 mm – Front Medium – – –
VW Crafter 2016 3.640 mm – Rear Normal – – –

Additional accessories:
Such as trays, hose holders or non-slip mats can be found from 18/928. 2 6 10 4
All VAROMOBIL-accessories are compatible also with VAROMOVE
5 9
1 3
Equipped VAROBOXXes and VAROiBOXXes:
Selec from more than 170 industry-specific assortments from page 18/640.
Availability subject to country specific rules and regulations. www.buypremiumtools.com 538
