Screwdrivers \ Slotted and Phillips screwdrivers
Slotted screwdrivers (DIN 5264)
Hexagonal blade and striking cap

Execution: Advantage:
ƒ End-to-end tempered hexagonal blade ƒ Impact-resistant blade
ƒ Hexagonal shoulder ƒ Black Point tip for longer service life and enhanced
ƒ Multi-component Kraftform handle with roll-away protection against corrosion
protection for sizes 3.5 mm to 10 mm ƒ Size 4.5 mm to 14 mm with steel cap for use as a
ƒ Black Point tip chisel
ƒ Size 12 and 14 mm/ident. no. 070 and 080 with ƒ Hexagonal shoulder for use with a wrench
1-C Weralit handle
Width of cutting edge 3.5 4.5 5.5 7 9 10 12 14
(mm)
Thickness of cutting edge 0.6 0.8 1 1.2 1.6 1.6 2 2.5
(mm)
Blade length (mm) 80 90 100 125 150 175 200 250
Length (mm) 161 188 205 230 262 287 317 367
Material of the grip handle 2-component 2-component 2-component 2-component 2-component 2-component 1-component 1-component
plastic
plastic
plastic
plastic
plastic
plastic
plastic
plastic
52765... Ident. No. 010 020 030 040 050 060 070 080
●
●
●
●
●
●
●
●
Prod. Gr. 542
Slotted, Phillips and TORX screwdriver set (DIN 5264)
Hexagonal blade and striking cap
Execution: ƒ Kraftform multi-component handle for optimum
ƒ Continuous, tempered and impact-resistant force transmission
hexagon blade ƒ Steel cap for use as a chisel
ƒ Black Point tip for longer service life and enhanced ƒ Hexagonal shoulder for use with a wrench
corrosion protection
Delivery:
In plastic rack to hang up
Composition of set Supplied blade widths: 3.5 mm/4.5 mm/5.5
mm/7 mm
Number of pieces in assortment/set 6
Tip size PH1 | PH2
52765... Ident. No. 800
●
Prod. Gr. 542
Cross-point screwdrivers (DIN 5260)
PH and PZ drives
Execution: Advantage:
ƒ End-to-end tempered hexagonal blade ƒ Impact-resistant blade
ƒ Multi-component Kraftform handle with roll-away ƒ Black Point tip for longer service life and enhanced
protection for sizes PH/PZ 1 to 3 protection against corrosion
ƒ Size PH 4 and PZ 4/ident. no. 040 and 140 with ƒ Steel cap for use as a chisel
1-C Weralit handle ƒ Hexagonal shoulder for use with a wrench
ƒ Black Point tip
Tip size PH1 PH2 PH3 PH4
Blade length (mm) 80 100 150 200
Length (mm) 178 205 262 317
Material of the grip handle 2-component 2-component 2-component 1-component
plastic
plastic
plastic
plastic
52767... Ident. No. 010 020 030 040
●
●
●
●
Prod. Gr. 542
XXL screwdriver sets
Circular blade
Execution: Advantage:
ƒ Screwdriver with power grip ƒ Multi-component handle for greater comfort
ƒ Ident. No. 010: ƒ Ident. No. 010:
ƒ Lasertip tip ƒ Micro-roughened, sharp-edged surface texture
ƒ round blades, slotted, cross-head and TX created by laser tip securely holds the screw-
ƒ Ident. No. 020: driver in the screw head
ƒ Workshop, VDE, screw chisel screwdrivers ƒ Cam-Out effect is reduced
ƒ round and hexagon blades, slotted, cross-head ƒ Lower contact force required Ident. No. 010 Ident. No. 020
and TX Delivery:
In plastic rack to hang up
Source: Hahn+Kolb Werkzeuge GmbH
