Hand tools \ Gripping pliers
combination pliers (ISO 5746)

Application: ƒ Long cutting edges for thicker cables
For gripping, holding and cutting. ƒ Ident. No. 005–140: Polished head
Execution: ƒ Ident. No. 205–340: Chrome-plated pliers
ƒ Special tool steel, forged and oil-hardened ƒ Ident. No. 320–340: VDE type according to DIN EN 60900
ƒ Blades also inductively hardened for hard and soft wire Advantage:
ƒ Gripping zones for flat and round material ƒ Ident. No. 120–340: Safe, ergonomic and fatigue-free working thanks to
two-component handles

Ident. No. 030 Ident. No. 130 Ident. No. 230
Ident. No. 330

Length (mm) 140 160 180 200 160 180 200 110
Surface Bare Bare Bare Bare Bare Bare Bare Chrome-plated
VDE certified No No No No No No No No
Material of the grip handle Polyvinyl Polyvinyl Polyvinyl Polyvinyl 2-component 2-component 2-component 2-component
plastic
plastic
chloride
chloride
chloride
plastic
plastic
chloride
Max. medium wire Ø
cutting capacity (mm) 2.8 3.1 3.4 3.8 3.1 3.4 3.8 2.5
53068... Ident. No. 005 020 030 040 120 130 140 205
●
●
●
●
●
●
●
●
Length (mm) 140 160 180 200 160 180 200
Surface Chrome-plated Chrome-plated Chrome-plated Chrome-plated Chrome-plated Chrome-plated Chrome-plated
VDE certified No No No No Yes Yes Yes
Material of the grip handle 2-component 2-component 2-component 2-component 2-component 2-component 2-component
plastic
plastic
plastic
plastic
plastic
plastic
plastic
Max. medium wire Ø 2.8 3.1 3.4 3.8 3.1 3.4 3.8
cutting capacity (mm)
53068... Ident. No. 210 220 230 240 320 330 340
●
●
●
●
●
●
●
Prod. Gr. 535
Pliers sets
Workshop and VDE
Execution: ƒ Cobra 250-mm water pump pliers, dipped handles
ƒ combination pliers, 180 mm, 2-component ƒ side cutters, 160 mm, 2-component handles,
handles, polished head polished head
VDE certified No
Number of pieces in 3
assortment/set (PCS)
53068... Ident. No. 003
●
Prod. Gr. 535
Pliers sets in textile belt bag
2 piece
Execution: ƒ Water pump pliers Cobra 150 mm, PVC dipped grip handles
ƒ Ident. No. 006: ƒ Sharp combination pliers 145 mm, 2-component grip handles
ƒ Water pump pliers Mini Cobra 125 mm Delivery:
ƒ Mini plier wrench 150 mm
ƒ Ident. No. 006–007: Both with PVC dipped handles In robust textile belt bag with riptape fastening
ƒ Ident. No. 007: Technical data:
ƒ Water pump pliers Cobra 150 mm ƒ VDE certified: No
ƒ Heavy-duty side cutters, 160 mm ƒ Material of the grip handle: Polyvinyl chloride
ƒ Ident. No. 008: ƒ Number of pieces in assortment/set: 2
Ident. No. 006 Ident. No. 007 Ident. No. 008
Set 006 Set 007 Set 008
53068... 53068... 53068...
Ident. No. Ident. No. Ident. No.
006 ● 007 ● 008 ●
Prod. Gr. 535
