General requirements \ Grease presses
Volumetric capacity 400 ml 400 ml
Max. working pressure (bar) 400 400
Connection thread M10 x 1 M10 x 1
Feed volume per stroke (cm³) 1.2 2.0
56235... Ident. No. - 010
●
PRESSOL = Prod. Gr. 5IE
MATO = Prod. Gr. 5JM
Accessories for 56235 005 56235 010
56235... Grease cartridge, 400 100 100
g Ident. No. ● ●
High-pressure hand lever grease press
As a set

Application: with articulated nosepiece, quick-change hose,
For lubricating pointed nosepiece, hollow nosepiece
Execution: Delivery:
ƒ Industry design with grease press 56235 010 Lever-type grease gun, nozzle tube with hydraulic
nosepiece, quick-change nozzle tube with sliding
ƒ In plastic case with oil-resistant inlay coupling, quick-change nozzle tube with articulated
ƒ Contents: Lever-type grease gun, nozzle tube with nosepiece, quick-change hose, pointed nosepiece,
hydraulic nosepiece, quick-change nozzle tube hollow nosepiece
with sliding coupling, quick-change nozzle tube
Volumetric capacity 400 ml
Max. working pressure (bar) 400
Connection thread M10 x 1
56235... Ident. No. 400
●
Prod. Gr. 5JM
Accessories for 56235 400
56235... Grease cartridge, 400 100
g Ident. No. ●
High-pressure hand lever grease gun COLOUR

Application: ƒ Precision pumping station without additional seals,
Ideal for grease up to NLGI 2 extremely reliable
ƒ DIN 1283, TÜV/GS test and TÜV marking on black
Execution: steel tube
ƒ With 5 different coloured handles - for better ƒ Fillable using 400 g grease cartridges or loose
assignment of special greases to different corre- grease
sponding lubrication points ƒ Filling and bleeding nipple
ƒ Full lift technology suction strength (high pressure
build-up)
Volumetric capacity 400 ml
Max. working pressure
(bar) 400
Connection thread M10 x 1
56237... Ident. No. 010
●
Prod. Gr. 575
Nozzle pipes and high-pressure hose lines
For high-pressure hand lever grease presses
Execution: ƒ Ident. No. 270–280: high-pressure hose line with thrust coupling; M 22 for flat
ƒ Ident. No. 200: grease nipple, 22 mm
ƒ Curved nozzle pipe, with hollow nosepiece ƒ Ident. No. 290–300: high-pressure hose line with thrust coupling; M 4 for flat
ƒ With hollow nosepiece grease nipple, 10 mm
ƒ Ident. No. 210: Curved nozzle pipe, with pointed nosepiece Advantage:
ƒ Ident. No. 220: Curved nozzle pipe, with hydraulic gripper nosepiece ƒ Ident. No. 230–300: Fail-safe, high-pressure reinforced rubber hose 13 mm in
ƒ Ident. No. 230–240: High-pressure hose line with hydraulic gripper nosepiece diameter, excellent occupational safety due to 1650-bar bursting pressure
ƒ Ident. No. 250–260: high-pressure hose line with thrust coupling; M 1 for flat
grease nipple, 16 mm Technical data:
ƒ Connection thread: M10 x 1

Ident. No. 230–240
Ident. No. 200 Ident. No. 210 Ident. No. 220 Ident. No. 270–280

Slide
Slide
Mouthpiece outlet Hollow die Extrusion Hydraulic Hydraulic Hydraulic Slide cou- Slide cou- coupling coupling Slide cou- Slide cou-
gripping
gripping
gripping
pling M4
die
pling M4
pling M1
pling M1
M22
die
M22
die
die
Length (mm) 150 150 150 300 500 - - - - - -
Hose length (mm) - - - - - 300 500 300 500 300 500
56235... Ident. No. 200 210 220 230 240 250 260 270 280 290 300
●
●
●
●
●
●
●
●
●
●
●
Prod. Gr. 5JM
