Chemical products

Engine Sealing Gasket K157

• high-temperature-resistant, pressure-resistant, permanently elastic
sealing compound for engine gasket surfaces, flange connections,
pressure tanks, compressors, screwed fastening etc.
• seals metal, glass and ceramic surfaces safely and permanently
• very good adhesion
• excellent chemical resistance
• simple heat curing
• with turnable dosing cap system
- convenient turnable cap for practical one-hand use
- continuously adjustable dosing system for optimized application,
low-consumption and thus cost-reducing dosing
- self-cleaning locking system, no clogging of the dispensing nozzle
• processing
- material is thermosetting, with heat addition (+70 °C to +100 °C) the
sealing compound is immediately ready for use
- apply material in a thin layer one-side only to clean and dry surface
- allow to dry for 5-10 min., then put parts together
- in case of repair the individual parts are relatively easy to
disassembled
• not suitable as cylinder head gasket

Technical Data
Base: Epoxy resin
Colour: red
Viscosity [mPas]: 5.500 – 6.500 mPas
Density (20°C) [g/cm³]: 1.08 g/cm³
Temperature resistance: from -50 °C to +280 °C
Max. Gap filling [mm]: 2.0 mm
Work life/Skin formation [Min.]: 5 – 7 min
Pressure resistance [bar]: 690 bar

Article No. Article Description
6480 4519 ENGINE SEAL. GASKET K157 100G
Red Seal Lock

• For the sealing and protection of screw connections and safety
components

Article No. Article Description
6490 4199 RED SEAL LOCK 100G

Holder for Sealing Compound/Adhesive 4-fold

Ø 47 mm
• Ideal for the storage of adhesive and sealant containers with Ø 40 mm
turnable dosing cap system
Ø 40 mm
• RAL 5003 blue Ø 35 mm
• Dimensions LxWxH: 230 x 60 x 60 mm
• Hole diameter: 1 x 47 mm, 2 x 40 mm, 1 x 35 mm
• Matching the VARO hole wall
• Matching the tool trolley Art.-No. 4990 179, Art.-No. 4990 660,
Art.-No. 4990 820, Art.-No. 4990 860 / 861

Diameter of Compound sealing / adhesive
Article-No. Article Description d=max Article-No. Article Description d=max
6410 4107 SUPERGLUE K186 5* BO. 5G 35 mm 6420 4005 SCREW LOCK.HIGH-TENS. K176 50G 40 mm
6410 4108 SUPERGLUE K186 5* BO. 30G 35 mm 6420 4018 FL(50G)ASS. SEALING HF K182 5* 40 mm
6410 4131 SUPERGLUE-CYBERSP.ADH.K187 20G 35 mm 6480 4519 ENGINE SEAL. GASKET K157 100G 40 mm
6410 4137 SUPERGLUE BLACK K188 5* 20G 35 mm 6420 4010 TB(50G)PI.THRE.SEAL.MF K177 5* 47 mm
6410 4139 SUPERGLUE HIGH VISCOS.K189 30G 35 mm 6420 4012 TB(50G)PI.THRE.SEAL.NF K178 5* 47 mm
6420 4000 SCREW LOCK MED. K175 50G 5* 40 mm 6480 4520 ORANGE SEAL. COMPOUND MED. 50G 47 mm

Article No. Article Description
4990 696 HOLDER FOR SEALING COMPOUND/AD

Technical data subject to change.
