Truckline

Jack 10 t

• Solid, blue steel frame
• Oil and acid resistant plastic wheels
• With pump lever for load and foot pedal for bridging idle stroke
• Patented LCS lowering valve guarantees the lowering with a control-
led rate of descent when working with heavy loads

Technical Data
Art. No. Load Str. height Str. height Frame Length Weight
cap.y max. min. height
t mm mm mm mm kg
5430 10 10 575 195 260 1600 112

Article No. Article Description QTY
5430 10 JACK 10T 1

Hydraulic car jack 5t

• hydraulic car jack with quick foot pedal to quickly span the lifting
point
• protection against uncontrolled dropping (dead man’s control)
• built-in safety valve to prevent overloading
• ergonomic handle

Technical Data
lifting capacity: 5 t
weight: 170 kg
lift height A min: 140 mm
lift height D max: 975 mm
dimensions LxB: 1290 x 525 mm
chassis height H: 265 mm
length lever C: 1200 mm

Article No. Article Description QTY
5430 5000 HYDRAULIC CAR JACK 5T 1

rubber wheel air filled

• for easy manoeuvring and for better steering
• suitable with 5 t trolley jack art. no. 5430 5000

Article No. Article Description QTY
5430 5001 P(2)RUBB.WHEELS F.CAR JACK 5T 1

Technical data subject to change.
