Truckline

Impact wrench 1” 2900 Nm Xi

• high performance impact wrench with metal housing for a very good
power-weight ratio
• runs right-left with the current 3-level torque setting
• extra narrow front with 89 mm Ø enables access to narrow spots
• side handle can be rotated 360°
• ergonomic handle with cold insulating rubber coating
• spindle length = 180 mm

Technical Data
art. no. 5350 2477
max torque: 2.900 Nm
square drive: 1”
operating pressure: 6.3 bar
continuous air consumption: 920 l/min
average air consumption: 300 l/min
sound level (LpA): 106 dB(A)
vibration: 9.8 m/s²
weight / total length: 8.1 kg / 490 mm
recommended hose Ø: 13 mm
air connection: 1/2” IG
suitable male coupling: art. no. 3926 12 8

Article No. Article Description QTY
5350 2477 1"IMPACT WR.LONG SPINDLE2477XI 1

Special Oil for Pneumatic Tools

• Provides longer service life of pneumatic tools

Article No. Article Description QTY
5354 100 SPECIAL AIR OIL 1000ML 1

Special hammer oil for compressed air tools

• for greasing the hammer part with regards impact wrenches with pin
clutch impact mechanisms

Article No. Article Description QTY
5354 101 SPEC.STRIKING MECH.OIL 1000ML 1

Technical data subject to change.
