Page 353 - Icon Ridge Electric Trade Catalog

Screwdrivers
Torque screwdrivers

Blades for TORX® and TORX-Plus® screws
to torque screwdrivers No. 52200 010-030

Application: Execution:
Ident. No. 106–125: For TORX® screws ƒ Hexagonal 6-mm drive
Ident. No. 206–225: For TORX®-Plus screws.
Technical Data:
ƒ Blade diameter: 1/4
Tip size TX6 TX7 TX8 TX9 TX10 TX15 TX20 TX25 TXP6 TXP7 TXP8 TXP9 TXP10 TXP15 TXP20 TXP25
Blade length (mm) 170 175 170 170 170 170 170 170 170 170 170 170 170 170 170 170
Ident. No.
109
110
107
108
106
210
209
215
225
220
208
125
120
115
207
206
52200... Unit price, € O. R. O. R. O. R. O. R. O. R. O. R. O. R. O. R. O. R. O. R. O. R. O. R. O. R. O. R. O. R. O. R.
Prod. Gr. 5HC
Bit holder
For torque screwdrivers no. 52200 010-030
Execution: ƒ Hexagonal 6-mm drive
Blade length (mm) 170
Blade Ø 1/4
400
Ident. No.
52200... Unit price, € O. R.
Prod. Gr. 5HC
easy Torque torque screwdrivers
With fixed factory setting of torque
Execution: ƒ Mechanism resistant to industrial lubricants
ƒ Click signal on reaching the set torque value
ƒ Quick identification by printed marking on end of Technical Data:
ƒ Handle length: 130 mm
handle ƒ Material of the grip handle: 2-component plastic
Advantage: ƒ Error limit (%): 10 %
ƒ Handle enables optimum force transmission ƒ Calibration certificate: No
ƒ Unlimited opening torque General tools
Max. torque measuring 0.5 0.6 0.9 1.1 1.2 1.4 2 2.5 3 3.8 4 4.5 5
range (Nm)
014
012
030
021
011
025
040
Ident. No.
050
045
038
006
009
52201... Unit price, € 005 O. R. O. R. O. R. O. R. O. R. O. R. O. R. O. R. O. R. O. R. O. R. O. R.
O. R.
Prod. Gr. 537
Torque screwdrivers
TorqueVario®-S with scale, with calibration certificate
Execution: scope of supply and services:
ƒ Variable torque adjustment With adjustment tool
ƒ With scale
ƒ SoftFinish® handle Technical Data:
ƒ Blade diameter: 4 mm
ƒ Automatic release and click signal ƒ Material of the grip handle: 2-component plastic
Advantage: ƒ Calibration certificate: Yes
ƒ Compact and particularly lightweight design
Min./max. torque measuring 0.1-0.6 Nm 0.4-1 Nm 0.8-2 Nm 1-5 Nm 2-8 Nm
range
Handle length (mm) 127 127 131 138 142
Error limit (%) (%) 10 6 6 6 6
130
Ident. No.
170
150
160
140
52206... Unit price, € O. R. O. R. O. R. O. R. O. R.
Prod. Gr. 537
Technical data subject to change.
