III. Control Communication
 Total No. of control boards : 02
a) SC – DHNE (Includes GWD – RC) : CTO-I
b) SC – MUE (Includes MJF-MLY & JKM-BDHN) : CTO-II
 Total Length of Control Section : 622.89 KM
a) Railway owned 6Q cable : 622.89 KM
b) Railway owned OFC : 619.89 KM
c) BSNL owned overhead alignment : NIL
 Total No. of EC sockets : 619
a) SC – DHNE (Includes GWD – RC) : 352
b) SC – MUE (Includes MJF-MLY & JKM-BDHN) : 267

 Radio Patching Facility for control
a) BSNL channels : 04
b) Digital MW or Radio Link : NIL
 Total No. of Manned LC Gates : 163
a) SC – DHNE (Includes GWD – RC) : 91
b) SC – MUE (Includes MJF-MLY & JKM-BDHN) : 72
 Passenger Amenities:
a) No. of stations having PA System
i. Micro Processor Based/IPIS PA System : 39
ii. GPS Based Auto Announcing System : 09
iii. Manual Announcement System : 10

b) PRS/UTS
i. Total No. of UTS Locations : 62
ii. Total No. of PRS Locations : 37

c) Indication Boards
i. No. of stations with Coach Indication Boards : 09
ii. No. of stations with Train Indication Boards : 16
iii. At A Glance Train Indication Boards : 24
iv. No. of stations with GPS Digital Clocks : 40

d) FOIS : 16
e) No. of stations with Wi-Fi : 62
f) No. of Station with Counter Communication System : 12
g) No. of station with Online Caution Order System : 09
h) No. of stations with Electronic Chart Display System : 02
i) No. stations with POET : 06
 Exchanges
a) Total No. of Telephone exchanges : 17
b) Exchanges in HQrs. Area : 08
c) Total No. of Railway Telephone Subscribers : 4960
 Total No. of 5W VHF Sets : 941

 Total No. of 25W VHF Sets : 64
 Total No. of CUG Connections (JIO -1875 & Airtel -106) : 1981
 Total No. of Station with RailNet : 12
 Total No. of RailNet Connections : 2486

a) Internet Bandwidth for Offices in SC (HQ & LGD) : 705 Mbps
b) Internet Bandwidth for Offices in HYB Division : 195 Mbps
c) IPDSLAM Bandwidth for LGD (528 Port X1) : 110 Mbps
d) IPDSLAM Bandwidth for RN (192 Port X2) : 50 Mbps
 Total No. of PT sets : 142
a) Diesel Loco at MLY – 84, SLR at KCG -58
246
