GENERAL



          Door Seals




          Door Seal — EPDM Rubber                             Door Seal

    ELECTRICAL
          „  Supplied in a 4.8 metre lengths.                 „  Soft EPDM compression seal with rigid PVC fixing strip.
                                                              „  Seal supplied in a 25 metre coil, fixing strip supplied in 10 x
                                                                2.55 metre lengths. Strip part number 252.
                                                              „  Drawing shows fixing strip in situ.



    EMERGENCY

                                             B

                                   A
                                                        D
    GENERAL
                                             C






    HANDLES

         Part No.  A  B   C  D                     Kg  Finish  Part No.  A  B  C  D                    Kg  Finish

         1232514  12  4.5  36  1.5                1.325  GR   67      19  40  4.5  15                  8.3  BP

          Aluminium Fixing Strip                              Door Seal
    HINGES

          „  Supplied in 3 metre lengths, drilled at 130mm centres with   „  D-Seal with 3M Backing Tape 100mtr
            5mm diameter holes.
          „  Sold in packs of 30.


    IRONWORK






    LIGHTING






    LOCKS




         Part No.     A   B   C  D   E             Kg  Finish  Part No.  A  B                          Kg  Finish
         30X081327481  10  2.5  3  1.5  15        7.35  MF    SVF1006  12  10                         5.105  BP
    STEPS
          Looking for....


          Waterproof speakers?                                                               See page 6




    VENTILATION
