PR OD U C T BU LLETIN 10-1GT
SEC TION 10
1-1-05
[ ]
N
M AG A GT
Gas Turbine Series

>

Glasfloss M agna GT filters are designed to withstand the rigors of a gas
turbine engine, centrifugal com pressor and other high velocity appli-
cations. Heavy-duty face grills and additional m edia pack rein-
forcem ents ensure the integrity of the filters under the m ost
M
dem anding conditions. The R series is suited for standard
> FEATURES capacity applications; the XL series provides additional m edia
for higher velocity applications. Glasfloss M agna GT filters
are available in 60-65% and 90-95% ASHRAE efficiencies.
Standard sizes are available in single or double header fram e
styles.

Glasfloss M agna GT filters shall be m anufactured with high efficien-
cy glass m icrofiber m edia that is gently pleated to for the m edia
m
pack. Rolled edge alu inu separators are inserted between each
m
m
pleat to provide an extensive open area for air flow and to stabilize the m edia
m
> CONSTRUCTION pack. A heavy-duty 26 gauge galvanized m etal fra e shall encapsulate the >
m edia pack. The entire m edia pack is sealed and bonded to the fra e to pre- · Heavy-duty Construction for Gas Turbine
m
vent air bypass and to ensure the integrity of the filter. Additionally, heavy-duty Applications
m etal face guards are installed on the air entering and air leaving sides of the · Glass M icrofiber M edia Provides
filters. · Excellent M oisture Resistance
Extra Durability for Demanding HVAC
· Applications
Standard and High Capacity Versions
m
Glasfloss M agna GT filters are ideally suited for de anding gas turbine and Available
m
centrifugal co pressor applications. In addition, M agna GT filters can be used
> APPLICATIONS in high velocity HVAC applications where filters with an extra m easure of dura-
m
bility and perfor ance are required.
The G lasfloss M agna G T frame shall be made of a 26 gauge gal-
A
vanized metal. 26 gauge galvanized steel header shall be used on
the metal frame. The media shall be constructed of a w ater resis-
tant, inorganic glass microfiber. For quality assurance, the glass
microfiber media rolls are randomly tested and certified to meet
minimum efficiency requirements by the media manufacturer. The
media pack shall consist of a continuous sheet of the pleated glass
microfiber. The pleated media pack is separated w ith multiple
rolled edge corrugated aluminum separators. The media cartridge
shall be sealed at the air entering, center and air leaving sides w ith
a sealant that bonds the media and separators to the interior of the
frame filter. 1/4" neoprene thick gasket shall be applied on the
A
> SPECIFICATIONS
filter. A n expanded metal face guard is installed on the air
entering and air leaving sides of the frame to insure filter
integrity and increase rigidity. The expanded metal shall be
galvanized to resist rust and corrosion. The filter shall be rated to
w ithstand temperatures up to 180 degrees Fahrenheit. The filters
shall be rated Class 2 under U . L. Std. 900 and w ithstand up to 11
in. w .g. in an “ ir Filter Breaching Test.” M agna G T Series shall
A
have the follo ing performance.
w
Efficiency 60-65 % 90-95 %
M ER V 11 14
“Serving You With Locations Throughout The Nation”
m
Glasfloss has a policy of uninterrupted research, develop ent and product i prove ent and reserves the right to change design and specifications without notice.
