D
MO EL SIZE SIZE R A TE D IN ITIA L ME IA SIZE R A TED IN ITIA L
D
N U MBE R W x H x D W x H x D V ELO IT Y R ESIST. SQ A R E W x H x D V ELO IT Y R ESIST.
C
C
U
N
A
N
N OMI A L E A C T FPM IN . .G. FEET N OMI A L M/H P SC A LS
X
W
R
MER V ME V MER V MM MER V MER V MER V
10 11 13 10 11 13
Z-Line 700 SG
SG P20256 20 x 25 x 6 19-3/4 x 24-1/4 x 6 300 .09 .11 .13 37.85 508 x 635 x 152 5490 22.4 27.4 32.3
SG P16276 16 x 27 x 6 15-3/8 x 27 x 6 300 .09 .11 .13 38.06 406 x 686 x 152 5490 22.4 27.4 32.3
A
SG P20256 C 20 x 25 x 6 19-3/4 x 24-1/4 x 6 300 .18 - - 37.85 508 x 635 x 152 5490 44.8 - -
A C = A ctivated Carbon
Z-Line 600 G A
G A P16205 16 x 20 x 5 15-3/8 x 21-7/8 x 5-1/4 300 .08 .09 .10 25.26 406 x 508 x 127 5490 19.9 22.4 24.9
G A P16255 16 x 25 x 5 15-3/8 x 25-1/2 x 5-1/4 300 .08 .09 .10 27.56 406 x 635 x 127 5490 19.9 22.4 24.9
G A P20205 20 x 20 x 5 20-1/4 x 20-3/4 x 5-1/4 300 .08 .09 .10 32.48 508 x 508 x 127 5490 19.9 22.4 24.9
G A P20255 20 x 25 x 5 20-1/4 x 25-3/8 x 5-1/4 300 .08 .09 .10 35.43 508 x 635 x 127 5490 19.9 22.4 24.9
A
A
Z-Line 500 B 300 B
&
A BP16255 16 x 25 x 5 15-3/4 x 24-1/4 x 4-7/8 300 .07 .08 .10 18.12 406 x 635 x 127 5490 17.4 19.9 24.9
A BP20205 20 x 20 x 5 19-3/4 x 20-3/4 x 4-7/8 300 .07 .08 .10 18.72 508 x 508 x 127 5490 17.4 19.9 24.9
A BP20255 25 x 20 x 5 24-1/4 x 19-3/4 x 4-7/8 300 .07 .08 .10 22.73 635 x 508 x 127 5490 17.4 19.9 24.9
A BP16253 16 x 25 x 3 15-7/8 x 24-1/4 x 2-7/8 300 .21 .23 - 11.50 406 x 635 x 76 5490 52.2 57.2 -
A BP20255A C 25 x 20 x 5 24-1/4 x 19-3/4 x 4-7/8 300 .14 - - 22.73 635 x 508 x 127 5490 34.8 - -
A
A C = ctivated Carbon Z-Line 400 H W
H WP13204 12-1/2 x 20 x 4 12-1/2 x 20 x 4-3/8 300 .08 .09 .11 9.75 318 x 508 x 102 5490 19.9 22.4 27.4
H WP16204 16 x 20 x 4 16 x 19-7/8 x 4-3/8 300 .08 .09 .11 12.48 406 x 508 x102 5490 19.9 22.4 27.4
H WP16254 16 x 25 x 4 16 x 24-7/8 x 4-3/8 300 .08 .09 .11 15.64 406 x 635 x 102 5490 19.9 22.4 27.4
H WP20204 20 x 20 x 4 20 x 19-7/8 x 4-3/8 300 .08 .09 .11 15.60 508 x 508 x 102 5490 19.9 22.4 27.4
H WP20254 20 x 25 x 4 20 x 24-7/8 x 4-3/8 300 .08 .09 .11 19.55 508 x 635 x 102 5490 19.9 22.4 27.4
W
Z-Line 400 H R
H WR12124 12 x 12 x 4 11-3/4 x 11-3/4 x 3-3/4 300 .10 .12 .14 5.14 305 x 305 x 102 5490 24.9 29.9 34.8
H WR12244 12 x 24 x 4 11-3/4 x 23-3/4 x 3-3/4 300 .10 .12 .14 12.37 305 x 610 x 102 5490 24.9 29.9 34.8
H WR14144 14 x 14 x 4 13-3/4 x 13-3/4 x 3-3/4 300 .10 .12 .14 7.09 356 x 356 x 102 5490 24.9 29.9 34.8
H WR14204 14 x 20 x 4 13-3/4 x 19-3/4 x 3-3/4 300 .10 .12 .14 11.32 356 x 508 x 102 5490 24.9 29.9 34.8
H WR14244 14 x 24 x 4 13-3/4 x 23-3/4 x 3-3/4 300 .10 .12 .14 13.61 356 x 610 x 102 5490 24.9 29.9 34.8
H WR14254 14 x 25 x 4 13-3/4 x 24-3/4 x 3-3/4 300 .10 .12 .14 14.82 356 x 635 x 102 5490 24.9 29.9 34.8
H WR14304 14 x 30 x 4 13-3/4 x 29-3/4 x 3-3/4 300 .10 .12 .14 18.05 356 x 762 x 102 5490 24.9 29.9 34.8
H WR16204 16 x 20 x 4 15-3/4 x 19-3/4 x 3-3/4 300 .10 .12 .14 13.37 406 x 508 x 102 5490 24.9 29.9 34.8
H WR16254 16 x 25 x 4 15-3/4 x 24-3/4 x 3-3/4 300 .10 .12 .14 18.87 406 x 635 x 102 5490 24.9 29.9 34.8
H WR18184 18 x 18 x 4 17-3/4 x 17-3/4 x 3-3/4 300 12.30 5490 24.9 29.9 34.8
.10
450 x 450 x 102
.14
.12
H WR18244 18 x 24 x 4 17-3/4 x 23-3/4 x 3-3/4 300 .10 .12 .14 18.55 450 x 610 x 102 5490 24.9 29.9 34.8
H WR18304 18 x 30 x 4 17-3/4 x 29-3/4 x 3-3/4 300 .10 .12 .14 21.88 450 x 762 x 102 5490 24.9 29.9 34.8
H WR20204 20 x 20 x 4 19-3/4 x 19-3/4 x 3-3/4 300 .10 .12 .14 18.52 508 x 508 x 102 5490 24.9 29.9 34.8
H WR20244 20 x 24 x 4 19-3/4 x 23-3/4 x 3-3/4 300 .10 .12 .14 22.27 508 x 610 x 102 5490 24.9 29.9 34.8
.12
H WR20254 20 x 25 x 4 19-3/4 x 24-3/4 x 3-3/4 300 .10 .14 23.66 508 x 635 x 102 5490 24.9 29.9 34.8
H WR20304 20 x 30 x 4 19-3/4 x 29-3/4 x 3-3/4 300 .10 .12 .14 28.80 508 x 762 x 102 5490 24.9 29.9 34.8
H WR24244 24 x 24 x 4 23-3/4 x 23-3/4 x 3-3/4 300 .10 .12 .14 27.21 610 x 610 x 102 5490 24.9 29.9 34.8
H WR24304 24 x 30 x 4 23-3/4 x 30-3/4 x 3-3/4 300 .10 .12 .14 34.64 610 x 781 x 102 5490 24.9 29.9 34.8
Tolerances shall be +/- 1/8” for height, width and +/- 1/16” depth. Recom m ended final resistance is .50” in. w. g.
U
N
A
ST N D A R D P ESSU R E R OP MIN IM M P R TIC LE SIZE EFFIC IE C Y
R
D
A
0.5 100
GE
.G. 0.4 80
TA
. W 0.3 EN 60
E IN C
0.2 40
L PER
C
N 0.1 20
ESISTA 0.0 A
250 300 350 400 450 500 EMOV 0 1 10
R .1
R
R
A
N
A IR FLO A TE, (FPM) P R TIC LE SIZE, MIC R O S
W
V
V
V
M ER -10 M ER -11 M ER -13 M ER -10 M ER -11 M ER -13
V
V
V
500 B 500 B 500 B
A
A
A
“Serving You With Locations Throughout The ation”
N
m
Glasfloss has a policy of uninterrupted research, develop ent and product i prove ent and reserves the right to change design and specifications ithout notice.
m
m
w
w w w .glasfloss.com · (214) 741-7056
