SWITCHES

Item Number Thermal Switch Temperature
SUI-10420 THermal Switch 35 ºC 10A 250VAC-Normal Close 35 ºC
SUI-10425 THermal Switch 45 ºC 15A 250VAC-Normal Close 45 ºC
SUI-10426 THermal Switch 45 ºC 15A 250VAC-Normal Open 45 ºC
SUI-10435 THermal Switch 150 ºC 15A 250VAC-Normal Close 150 ºC
SUI-10445 THermal Switch 168 ºC 15A 250VAC-Normal Close 168 ºC
THermal Switch
SUI-10420 THermal Switch 240 ºC 15A 250VAC-Normal Close 240 ºC THermal Switch

Item Number Thermal Fuse Temperature
FUS-11600 Thermal Cut-Off Fuse 15-10A/120-250VAC 240 °C
FUS-11610 Thermal Cut-Off Fuse 15-10A/120-250VAC 250 °C
FUS-11605 Thermal Cut-Off Fuse 15-10A/120-250VAC 252 °C Thermal Cut-Off Fuse

SUI-10265 SUI-10260 SUI-10106
Micro Switch-W/Roller,3 Pins Micro Switch With Length Micro Switch-3 Pins
SPDT-6A/250VAC Level 50mm 3-Pins SPDT SPDT-6A/250VAC
6A/250VAC

SUI-10250 SUI-10240
Micro Switch-W/Roller,3 Pins Micro Switch 3 Pins-SPDT
SPDT-6A/250VAC SPDT-6A/250VAC

7.8

SUI-11740 SUI-11845 SUI-11635 SUI-11530
Tact Switch Tact Switch Tact Switch Tact Switch
Rating: 0.3A/12VDC Rating: 0.3A/12VDC Rating: 0.3A/12VDC Rating: 0.3A/12VDC

ARTICLIGHTING.COM LEXAUDIO.US REVOLUTIONPRO.COM NETCOMLAB.COM VIVALDIMUSIC.COM
121
