Internal Hex
Internal Hex

Body
Height
Collar
Height

Wide range of collar Cat. Number CO-TBR1 CO-TBR2 CO-TBR3 CO-TBR4
and body sizes Collar Height [mm] 1 1 3 3
Body Height [mm]
4
6
6
4
Torque [Ncm] 30 30 30 30
Conical Connection

Body
Height
Collar
Height

Cat. Number MPN-TBR1 MPN-TBR2 MPN-TBR3
Collar Height [mm] 1 2 3
NP
Body Height [mm] 4 4 4
Torque [Ncm] 20 20 20

Body
Height
Collar
Height

Cat. Number MPR-TBR1 MPR-TBR2 MPR-TBR3 MPR-TBR4
Collar Height [mm] 1 2 3 4
RP
Body Height [mm] 4 4 4 4
Torque [Ncm] 30 30 30 30 D IGI T AL SOL U TIONS

Body
Height
Collar
Height

Cat. Number MPW-TBR1 MPW-TBR2 MPW-TBR3 MPW-TBR4
Collar Height [mm] 1 2 3 4
WP
Body Height [mm] 4 4 4 4
Torque [Ncm] 30 30 30 30
