Rod Reduction

Option 3

(1) The upper fork must be slid onto the upper ring of the rod

persuader,

(2) The lower fork must be slid onto the upper ring of the screw

extender. Use the laser marks (3) to find the appropriate position
D for the rod persuader plier.

> 45mm

1

2

(3)

GMS2-ST_04GB See package insert for labeling limitation 49
