STYLE AND CONSTRUCTION                                         4

             4-layer Intellicore  polyurethane insulated steel faux wood doors.   LAYER
                           ®
            ■
             18.4 R-value.                                               POLYURETHANE
             Multiple door designs and window options. Custom designs also
            ■                                                            1  COMPOSITE
             available. See your Clopay Dealer for more information.       OVERLAY            3
              Many glass options available including clear, frosted, seeded, rain and   STEEL WITH
            ■                                                            2  ULTRA-GRAIN ®              2    1
             obscure as well as insulated. See page 41 for specialty glass options.  PAINT FINISH
              Attractive beveled edge clip-in grilles are removable for easy cleaning.  3  2" INTELLICORE ®
                                                                           INSULATION
            ■
                                                                                                4
              Comes complete with spade lift handles and step plates.    4  STEEL
            ■
             See pages 42–43 for details.
             Calculated door section R-value is in accordance with DASMA TDS-163.
             Canyon Ridge ®  Collection not applicable for new construction in California areas designated as “Fire Hazard Severity Zones”.
            DOOR DESIGNS
            SERIES 1                                SERIES 3






              Design 11   Design 12    Design 13      Design 31   Design 32    Design 33   Design 34
            SERIES 2






              Design 21   Design 22    Design 23      Design 35   Design 36    Design 37   Design 38
            All doors shown in Medium Finish with Clear Cypress overlay.

            TOP/ WINDOW SECTIONS




                   TOP11               TOP12                TOP13               ARCH1



                   REC11               REC13                REC14                SQ23                SQ24


                   ARCH1               ARCH3               ARCH4                     ARC4A (Double Door)
                                                                                Additional double width door designs available.
            MATERIAL DESIGN OPTIONS                            COLORS

                                                                                           Composite Overlays and Window Grilles
              COMPOSITE OVERLAY     ULTRA-GRAIN ®  BASE STEEL      Ultra-Grain      Medium Finish  color will vary slightly within a door due
                                                                                           are finished in the same color as the
                                                                                           Ultra-Grain  base door. Door stain
                                                                                                 ®
                                                                                           to finishing process. Due to the printing
                                                                                Ultra-Grain
                                                                         ®
                                                                                       ®
                                                                                           process, colors may vary.
                                                                                 Cypress
                                                                  Cypress
                                                                  Walnut Finish
                                                               WARRANTIES
                                                                COMPOSITE OVERLAY   HARDWARE  STEEL
                                                                 DELAMINATION      PAINT SYSTEM
                     Clear Cypress                               LIMITED  LIMITED  LIMITED
                                                                 5 YR     5 YR     LIFE
            Composite Cladding is not present on Ultra-Grain  Series Models.  WARRANTY  WARRANTY  WARRANTY
                                      ®
