What's NeW fleet / traNsPortatIoN
ez ClIP fIeld attaChable a/C hose eNds
90° elboW female o-rINg short PIlot
straIght female o-rINg loNg PIlot W/sWItCh Port
Part No.
MFG No.
Fitting Dimension A (Hose) (Inches)
Fitting Dimension B (Working End)
57200
FJ3162-0808S
13/32 (-8)
3/4-16 (-8)
57201
FJ3162-1010S
1/2 (-10)
7/8-14 (-10)
57202
FJ3162-1012S
5/8 (-12)
7/8-14 (-10)
Part No.
MFG No.
Fitting Dimension A (Hose) (Inches)
Fitting Dimension B (Working End)
57211
FJ5985-0606S
5/16 (-6)
5/8-18 (-6)
57212
FJ5985-0608S
13/32 (-8)
5/8-18 (-6)
57214
FJ5985-0808S
13/32 (-8)
3/4-16 (-8)
57215
FJ5985-0810S
1/2 (-10)
3/4-16 (-8)
57216
FJ5985-1010S
1/2 (-10)
7/8-14 (-10)
57217
FJ5985-1012S
5/8 (-12)
7/8-14 (-10)
57218
FJ5985-1212S
5/8 (-12)
1 1/16-14 (-12)
45° female o-rINg
loNg PIlot W/sWItCh Port
90° female o-rINg
short PIlot W/r134a loW sIde Port
Part No.
MFG No.
Fitting Dimension A (Hose) (Inches)
Fitting Dimension B (Working End)
57220
FJ3230-03-0808S
13/32 (-8)
3/4-16 (-8)
57221
FJ3230-04-1010S
1/2 (-10)
7/8-14 (-10)
57222
FJ3230-02-1012S
5/8 (-12)
7/8-14 (-10)
Part No.
MFG No.
Fitting Dimension A (Hose) (Inches)
Fitting Dimension B (Working End)
57279
FJ3012-02-1010S
1/2 (-10)
7/8-14 (-10)
57280
FJ3012-01-1012S
5/8 (-12)
7/8-14 (-10)
90° elboW female o-rINg loNg PIlot
90° female o-rINg
short PIlot W/r134a hIgh sIde Port
Part No.
MFG No.
Fitting Dimension A (Hose) (Inches)
Fitting Dimension B (Working End)
57223
FJ3288-01-0606S
5/16 (-6)
5/8-18 (-6)
57224
FJ3288-02-0808S
13/32 (-8)
13/32 (-8)
Part No.
MFG No.
Fitting Dimension A (Hose) (Inches)
Fitting Dimension B (Working End)
57282
FJ3013-03-0808S
13/32 (-8)
3/4-16 (-8)
57283
FJ3013-01-0810S
1/2 (-10)
3/4-16 (-8)
90° female o-rINg
loNg PIlot W/sWItCh Port
straIght female o-rINg
short PIlot W/r134a hIgh sIde Port
Part No.
MFG No.
Fitting Dimension A (Hose) (Inches)
Fitting Dimension B (Working End)
57277
FJ3289-01-0808S
13/32 (-8)
3/4-16 (-8)
57278
FJ3289-02-1010S
1/2 (-10)
7/8-14 (-10)
Part No.
MFG No.
Fitting Dimension A (Hose) (Inches)
Fitting Dimension B (Working End)
57203
FJ3053-0808S
13/32 (-8)
3/4-16 (-8)
