What's NeW eleCtrICal
WraP 'N' seal heat shrINk WraP
A superior wraparound insulation product that easily installs in repair and splice applications providing excellent insulation and protection for cable jackets
eleCtrICal taPe maxx grIP
• Heavy duty 8.5-mil tape
• Extra thickness provides added electrical properties, quicker insulation
build up and abrasion resistance
• Flame-retardant, cold and weather-resistant with superior cold-weather
handling features
• Resistant to abrasion, salt, alkalies, acids and ultraviolet rays
Available June 1
*Dispensing carton
features aNd beNefIts
• 3:1 shrink ratio
• Shut down of system not required for repair
• High shrink ratio covers even irregular shapes
• Better split resistance than competitive products
• Thermoplastic adhesive liner provides complete
environmental protection and insulation
• Continuous operating temperature: -67°F to 230°F
• Shrink temperature: 250°F
staNdards
• Meets ICEA and NEMA insulation thickness specifications
tyPICal aPPlICatIoNs
• Cable jacket repair
• Retrofit protection of connectors
• Low voltage cable splicing
• Conduit repair
12" leNgths
Available June 1
4280
Part No.
Size
Roll
Dispenser of 10
4284
4280*
3/4" x 66 ft. Roll
Part Number
Expanded
Recovered
600/1000 V Single Conductor Size
Internal Diameter (min) D
Internal Diameter (min) D
Wall Thickness (nom) W
AWG/MCM
44573
1.20 inches
0.47 inches
0.08 inches
#1 - 3/0
44574
1.80 inches
0.60 inches
0.80 inches
2/0 - 400
44575
2.70 inches
0.95 inches
0.80 inches
400 - 1000
the information contained hereon is the confidential/trade secret information of tifco industries, inc. reproduction and/or distribution is strictly prohibited. WN-19
