Page 116 - SLV-NA_BL17_Intro+Icons.indd

116 CEILING LIGHTS INDOOR · BIG LIGHT 2017

PARRY 3 PARRY 3
Surface Spot Surface Wash

• 1370-1415 lumens • 1120 lumens
• Surface mount to match the Parry architectural • Surface mount to match the Parry architectural
track track
• Accessories include 18° and 42° field
interchangeable reflectors

Lamp details Lamp details
LED 1x 20W 3000K CRI>90 LED 1x 20W 3000K CRI>90
Product details Product details
120V 120V
Total consumption: 20W Total consumption: 20W
Material: Aluminum Material: Aluminum
Ø: 2.75 in. L: 3.9 in. Ø: 2.75 in. L: 4.3 in.
dimmable: L, C, Triac dimmable: L, C, Triac
Canopy Ø: 5 in. Canopy H: 0.5 in. Canopy Ø: 5 in. Canopy H: 0.5 in.

25° 1.36 50000 0.87 50000 355°

355° 300° 300°
Series available in other variants Series available in other variants
Product family Parry see page 014–019. Product family Parry see page 014–019.
Note Note
For use with octagon J-Box. For use with octagon J-Box.

4.3”
3.9” 2.75”
2.75”
Rec. accessory Item No.
Reflector, 18° 781073U
Reflector, 42° 781075U
Cross Baffle 781077U
Variant Item No. Variant Item No.
1400lm 1120lm
White 712061U White 712071U
Black 712060U Black 712070U

SLV-NA_BL17_10_Indoor-CEILING_170221_Feinlayout.indd 116 08.03.17 13:47
