BIG LIGHT 2017 ∙ OUTDOOR WALL LIGHTS 179

ROX ROX BIG ROX
Up/Down 15, LED Down 7.5, LED Up/Down 15, LED

• 504 lumens up and 504 lumens down • 762 lumens • 1447 lumens up and 1447 lumens down
• Architectural LED wall mounts • Architectural LED wall mounts • Architectural LED wall mounts
• Contemporary up/down design • Contemporary design • Contemporary up/down design

Lamp details Lamp details Lamp details
LED 2x 7.5W 3000K CRI>80 LED 1x 7.5W 3000K CRI>80 LED 2x 13W 3000K CRI>80

Product details Product details Product details
120-277V 120-277V 120-277V
Total consumption: 15W Total consumption: 7.5W Total consumption: 26W
Material: Aluminum/Glass Material: Aluminum/Glass Material: Aluminum/Glass
Ø: 2.76 in. H: 8.07 in. D: 3.78 in. Ø: 2.76 in. H: 5.2 in. D: 3.78 in. Ø: 4.92 in. H: 7.28 in. D: 6.14 in.
dimmable: C dimmable: C dimmable: C
Canopy Ø: 6 in. Canopy H: 0.5 in. Canopy Ø: 6 in. Canopy H: 0.5 in. Canopy Ø: 6 in. Canopy H: 0.5 in.

28° 2.3 28° 1.68 30000 24° 3.92

30000 30000
Series available in other variants Series available in other variants Series available in other variants
Product family Rox see page 014–019. Product family Rox see page 014–019. Product family Rox see page 014–019.

2.76” 2.76” 4.92”

5.2” 7.28”
8.07”
3.78”
3.78” 6.14”

Variant Item No. Variant Item No. Variant Item No.
1008lm 762lm 2894lm
White 751741U White 751751U White 751761U
Anthracite 751744U Anthracite 751754U Anthracite 751764U
Bronze 751748U Bronze 751758U Bronze 751768U
