214 CUSTOMER INFORMATION BIG LIGHT 2017

CUSTOMER INFORMATION

Luminous flux Stainless steel 316
The total amount of light generated by a light source is given in Lumens [lm]. (1.4404) Has excellent corrosion resistance suited to natural environmental
media (water, urban and rural atmospheres) as well as in industrial areas with
Luminous intensity moderate concentrations of chlorine and salt, in the food and pharmaceutical
The luminous intensity is the luminous flux per given angle specified, it is industries and in the agricultural food sector. 1.4404 is not sea water resistant.
given in Candela (cd).
Color rendering index
The color rendering properties of a light source are described using the Please note:
Ra Index (Color Rendering Index). The majority of SLV luminaries offer a CRI A large proportion of the products presented in this catalog are protected by
of 90 or higher. trademarks, registered design, industrial design or patents. Violation of the
protective rights or use of text and layout design without our permission will
Color of light be prosecuted. All products of our range are subjected to stringent
The color of light produced by a light source is given in Kelvin [K]. quality assurance measures and meet all of the generally applicable
standards.
Standard LED
This is the classic version of an LED (3 mm or 5 mm LED). These were Warranty: Information pertaining to SLV warranties can be found on our
originally designed for indication purposes, e. g. in instrument panels. website, slvlighting.com.
Standard SMD LED The illustrations and specifications contained in this catalog are for
SMD stands for Surface Mounted Device. It is a compact LED without wire illustration purposes only and are not binding in terms of color, shape,
connectors, rather with direct soldering onto the PCB. SMDs are available in design and technical specifications. This catalog contains a general range
various sizes and are well suited for illumination purposes. and is not designed to be country-specific. Any deviations from country-
specific regualtions must be clarified before an order is placed. SLV is not
PowerLED liable for any other technical standards, where applicable.
A PowerLED is a powerful LED with 1W or more power. It places increased All weight and length data are presented in in pounds and inches, unless
demands on the current stability and therefore has to be used with constant otherwise indicated.
current sources. If multiple LEDs are connected, they must therefore be
connected in series. Connecting in parallel is not permitted. In addition, The presentation of our luminaires with realistic and exemplary application
please pay attention to the installation sequence so that LEDs are not photographs has been made possible by the friendly cooperation and
exposed to high currents for short periods of time as they could be agreement of the owner or designer of each property shown in the
damaged. In general, the following applies: First completely connect the foreground of the pictures. Once again, we would like to take this opportunity
secondary circuit (LEDs to the driver), then connect the primary circuit (driver to thank those who gave their permission for the photographs to be taken
to the power source). and used in this publication.
Chip On Board LED (COB LED); Flat LEDs
This is an LED with an extremely flat shape. The advantage of COB LEDs
is that they have good heat dissipation for technical implementation with
cool surfaces, providing the possibility of high luminous efficiency with long Copyright
service life. © SLV GmbH, 2017
All pictures, text and graphics are subject to copyright
Stainless steel 304 and other laws to protect intellectual property.
(1.4301) Has good corrosion resistance suited to natural environmental media
(water, urban and rural atmospheres) without the presence of significant Photo credits:
concentrations of chlorine and salt. 1.4301 is, however, not suitable for use SLV GmbH
in areas where there is contact with sea water or salt water or a salt-laden SLV North America
atmosphere, nor for use in swimming pools or similar environments. SLG Kunststoff GmbH
