BIG LIGHT 2017 ∙ INDOOR RECESSED LIGHTS 045

MINI TRIA HOUSING MINI TRIA MINI TRIA
IC, Square Light Engine, Square, Wall Wash Light Engine, Square, Wall Wash

• ICAT Housing, for insulated ceilings and air-tight • 840-1060 lumens • 840-1060 lumens
installations • Petite 2" aperture • Petite 2" aperture
• The 0-10V dimming option is 120-277V • Available in additional color temperatures and • Available in additional color temperatures and
voltages; contact customer service voltages; contact customer service
Lamp details Lamp details
LED 1x 18W CRI>90 LED 1x 18W CRI>90

Product details Product details Product details
120V 120V 120V
Material: Aluminum Total consumption: 18W Total consumption: 18W
L: 11.25 in. W: 10.75 in. H: 7.25 in. Material: Aluminum Material: Aluminum
L: 2.75 in. W: 2.75 in. H: 3.85 in. L: 2.75 in. W: 2.75 in. H: 3.85 in.
dimmable: L, C, Triac dimmable: L, C, Triac

3.16 0.74 50000 0.74 50000

Series available in other variants Series available in other variants Series available in other variants
Product family MiniTria see page 014–019. Product family MiniTria see page 014–019. Product family MiniTria see page 014–019.
Note Note
Use with IC Housing ELV Dimming (781289U) or Use with IC Housing ELV Dimming (781289U) or
IC Housing 0-10V Dimming (781311U). IC Housing 0-10V Dimming (781311U).

2.4” 2.4”

7.25”
3.85” 3.85”
11.25”

10.75” 2.75” 2.75”

Variant Item No. Variant Item No.
3000K 840-1060lm 3000K 840-1060lm
White 705251A Dark Blue 705257A
Gold 705255A Black 705253A
Variant Item No. 2700K 840-1060lm 2700K 840-1060lm
IC Housing, square, ELV dimming 781291U White 705291A Dark Blue 705297A
IC Housing, square, 0-10V dimming 781311U Gold 705295A Black 705293A
