Page 158 - Eurotec-Ltd-Price-Book-2017-2018-Online

Terms and Conditions apply. Subject to change without notice Prices are GST Exclusive Items per unit unless otherwise stated
Visual & Audio Warning Beacons & Towers

Series 180 Beacons

¤ Minimum Complete Assembly = Terminal Unit +
Indicators + Cover + LED’s
¤ Standardised LED Bulbs Across The Range
¤ 60mm Ø, Modular Warning Tower - IP54 (to EN 60529)
¤ Ambient Operating Temperature -20° to +40°C
¤ Light Source = BA15d (23 x 47mm) Multi LED Bulb
¤ Material = Polycarbonate (Extension Pole Aluminium)
¤ Max Cable Size = 1.5mm²
¤ Double Insulated (Plastic Conmponents); Class II In
Accordance With IEC536
¤ Standards: Electromagnetic Compatibility EEC 89/336
European Compliance EN 60947-5-1
Low Voltage EEC 2006/95
EEC 94/68
Vibration 2g/min EN 60068-2-6

Series 370 Towers
¤ Minimum Complete Assembly = Terminal Unit + Indicators + Cover + LED’s
¤ Audio Modules Come Complete With Cap & Must Be The Top Mounted Module
¤ 70mm Ø, Modular Warning Tower - IP64 (to EN60529)
¤ Light Source = BA15d (23 x 47mm) Multi LED Bulb
¤ Material = Polycarbonate (Extension Pole Aluminium)
¤ Max Number Of Modules = 7 (Except Single Beacon Type = 2 Modules)
¤ Max Cable Size = 1.5mm²
¤ Double Insulated (Plastic Conmponents); Class II In Accordance With IEC536
¤ Standards: Electromagnetic Compatibility EEC 89/336
European Compliance EN 60947-5-1
Low Voltage EEC 73/23
EEC 94/68
Vibration 2g/min EN 60068-2-6

AUCKLAND 09-579 1990 WELLINGTON 04-499 3591 CHRISTCHURCH 03-366 0017 157
HVAC - Refrigeration - Electrical - Measurement www.eurotec.co.nz
